A-B 1734-ACNR 网络适配器
1.产 品 资 料 介 绍：
中文资料：
Allen-Bradley 1734-ACNR 网络适配器 是专为 ControlNet 网络 设计的设备，它可以将 POINT I/O 模块 连接到 ControlNet 网络中，支持分布式 I/O 系统。
主要特点：
- 高速数据传输：适配器支持高速的实时数据交换，确保设备与控制系统之间的快速通讯。
- 冗余功能：它支持 网络冗余 和 控制器冗余，提供更高的系统可靠性和容错能力。
- 抗干扰能力：在工业环境中，适配器具备较强的抗电磁干扰（EMI）能力，保证稳定运行。
- 网络供电：适配器能够通过网络获得供电，简化了布线和安装工作。
技术规格：
- 电源要求：输入电压为 24V DC，支持宽电压范围 10–28.8V DC。
- 功耗：功耗为 8W，最大功率损耗为 2.8W。
- POINTBus 电流：提供最大 1000 mA 的 5V 电流，支持多个 I/O 模块。
- 模块容量：最多支持连接 63 个 I/O 模块。
应用领域：
- 工业自动化：用于将 POINT I/O 模块集成到 ControlNet 网络中，帮助实现灵活的自动化控制。
- 过程控制：在需要高速和可靠数据传输的过程控制系统中应用。
- 制造业：用于实时数据采集与控制，连接各类现场设备。
安装与兼容性：
- 安装方式：可以方便地通过 DIN 导轨进行安装，符合工业标准。
- 兼容性：与 Allen-Bradley 的 POINT I/O 模块和 ControlNet 网络完美兼容。
Allen-Bradley 1734-ACNR 网络适配器，凭借其冗余设计、高速数据传输和强抗干扰能力，是在要求高可靠性和稳定性的工业自动化环境中理想的网络连接方案。
英文资料：
The Allen Bradley 1734-ACNR network adapter is a device designed specifically for ControlNet networks, which can connect POINT I/O modules to the network and support distributed I/O systems.
Main features:
High speed data transmission: The adapter supports high-speed real-time data exchange, ensuring fast communication between the device and the control system.
Redundancy function: It supports network redundancy and controller redundancy, providing higher system reliability and fault tolerance.
Anti interference capability: In industrial environments, adapters have strong anti electromagnetic interference (EMI) capabilities to ensure stable operation.
Network power supply: The adapter can obtain power through the network, simplifying wiring and installation work.
Technical specifications:
Power requirements: Input voltage is 24V DC, supporting a wide voltage range of 10-28.8V DC.
Power consumption: The power consumption is 8W, and the maximum power loss is 2.8W.
POINT Bus current: Provides a maximum of 1000 mA of 5V current and supports multiple I/O modules.
Module capacity: Supports up to 63 I/O modules for connection.
Application areas:
Industrial automation: used to integrate POINT I/O modules into the ControlNet network, helping to achieve flexible automation control.
Process control: applied in process control systems that require high-speed and reliable data transmission.
Manufacturing industry: used for real-time data collection and control, connecting various on-site devices.
Installation and compatibility:
Installation method: It can be easily installed through DIN rails, in compliance with industry standards.
Compatibility: Perfectly compatible with Allen Bradley's POINT I/O module and ControlNet network.
The Allen Bradley 1734-ACNR network adapter, with its redundant design, high-speed data transmission, and strong anti-interference capability, is an ideal network connection solution in industrial automation environments that require high reliability and stability.
2.产 品 展 示
