07AI91 模拟输入输出模块

ABB  07AI91  模拟输入输出模块   该模块具有8个模拟输入通道，这些通道可以成对配置，用于连接各种传感器，如温度或电压传感器。

ABB  07AI91  模拟输入输出模块  详情介绍：

07AI91模拟输入输出模块是一款功能强大的模块，具有多种特点和优势。

在模拟量输入方面，该模块具有8个模拟输入通道，这些通道可以成对配置，用于连接各种传感器，如温度或电压传感器。此外，该模块还支持Pt100、Pt1000线性化以及热电偶类型J、K和S线性化。需要注意的是，该模块只能使用电隔离传感器。每个通道使用16位进行配置，并且模块的地址设置由DIL开关执行。

在模拟量输出方面，该模块的主要功能是将输入的数字信号转换成数模，输出可调的连续电压、电流和信号。例如，在电视控制块中，可以通过模拟输出模块的数模转换，输出随输入信号变化的连续电压信号，从而控制音量、亮度和对比度等。

此外，该模块采用24v直流供电，并且其CS31系统总线连接与设备的其余部分是电隔离的。这意味着模块在运行时具有较高的安全性和稳定性。同时，该模块还提供了许多诊断功能，可以对所有通道进行自校准，进一步增强了其可靠性。

总的来说，07AI91模拟输入输出模块是一款功能全面、性能稳定的模块，适用于各种需要精确模拟量输入和输出的应用场景

ABB  07AI91  模拟输入输出模块  实物图片：

ABB  07AI91  模拟输入输出模块  实物视频

ABB 07AI91 Analog Input/Output Module Details Introduction:

The 07AI91 analog input/output module is a powerful module with multiple characteristics and advantages.

In terms of analog input, this module has 8 analog input channels that can be configured in pairs to connect various sensors, such as temperature or voltage sensors. In addition, the module also supports Pt100, Pt1000 linearization, as well as thermocouple types J, K, and S linearization. It should be noted that this module can only use electrically isolated sensors. Each channel is configured using 16 bits, and the address setting of the module is executed by the DIL switch.

In terms of analog output, the main function of this module is to convert the input digital signal into digital analog, and output adjustable continuous voltage, current, and signal. For example, in a TV control block, a continuous voltage signal that varies with the input signal can be output through the analog-to-digital conversion of the analog output module, thereby controlling volume, brightness, and contrast.

In addition, the module is powered by 24V DC and its CS31 system bus connection is electrically isolated from the rest of the equipment. This means that the module has high security and stability at runtime. At the same time, the module also provides many diagnostic functions that can self calibrate all channels, further enhancing its reliability.

Overall, the 07AI91 Analog Input/Output Module is a comprehensive and stable module, suitable for various application scenarios that require precise analog input and output
