SA801F 电源模块

发布时间:2024-04-10人气:
  • SA801F 电源模块
  • SA801F 电源模块
  • SA801F 电源模块

ABB   SA801F 电源模块    是一款专为工业自动化应用设计的紧凑型多功能电源模块。

ABB   SA801F 电源模块     详情介绍:

SA801F电源模块是一款专为工业自动化应用设计的紧凑型多功能电源模块。以下是该电源模块的主要产品特点:

  1. 宽输入电源范围:SA801F电源模块具有115~230VAC的宽输入电源范围,这使得它能够在不同的电压环境下稳定工作,满足了工业自动化应用中的多样化需求。
  2. 高效的输出能力:模块提供了3.3VDC+/—3% 5A和5.0VDC+/—3% 5A的输出,总输出功率为26.5W,确保为连接的设备提供稳定且高效的电力供应。
  3. 多重保护功能:SA801F电源模块具备短路及过载保护功能,可以在异常情况下保护电源和连接的设备,提高系统的可靠性。此外,当电源故障时,该模块还可以保持至少20ms的输出,为设备提供足够的缓冲时间。
  4. 状态监控与故障指示:电源模块提供了输入及输出电压监控功能,并能提供电源故障信号。这使得用户可以实时了解电源的工作状态,及时发现并处理潜在问题。
  5. 易于集成:SA801F电源模块只能插入到AC800F控制器最左边的P槽,这样的设计简化了安装和配置过程,使得模块能够轻松集成到现有的工业自动化系统中。
  6. 附加功能丰富:除了基本的电源供应功能外,该模块还设置了AC800F控制器的基本操作按钮及控制运行状态指示灯显示,方便用户进行日常操作和维护。此外,它还配备了诊测接口(带EMC滤波),用于诊测数据的EEPROM,以及AC800F CPU主板的状态检测及操作元件。

综上所述,SA801F电源模块以其宽输入范围、高效输出、多重保护、状态监控、易于集成以及丰富的附加功能等特点,为工业自动化应用提供了稳定可靠的电源解决方案。

ABB   SA801F 电源模块      实物图片:


ABB   SA801F 电源模块     实物视频

ABB SA801F power module details introduction:

The SA801F power module is a compact multifunctional power module designed specifically for industrial automation applications. The following are the main product features of this power module:

Wide input power range: The SA801F power module has a wide input power range of 115~230VAC, which enables it to work stably in different voltage environments and meet the diverse needs of industrial automation applications.

Efficient output capability: The module provides 3.3VDC+/-3% 5A and 5.0VDC+/-3% 5A outputs, with a total output power of 26.5W, ensuring stable and efficient power supply for connected devices.

Multiple protection functions: The SA801F power module has short-circuit and overload protection functions, which can protect the power supply and connected equipment in abnormal situations and improve system reliability. In addition, when the power supply fails, the module can maintain an output of at least 20ms, providing sufficient buffering time for the device.

Status monitoring and fault indication: The power module provides input and output voltage monitoring functions, and can provide power fault signals. This allows users to have real-time understanding of the working status of the power supply, and to promptly identify and address potential issues.

Easy to integrate: The SA801F power module can only be inserted into the leftmost P slot of the AC800F controller. This design simplifies the installation and configuration process, allowing the module to be easily integrated into existing industrial automation systems.

Rich additional features: In addition to the basic power supply function, this module also features the basic operation buttons and control operation status indicator lights of the AC800F controller, making it convenient for users to perform daily operations and maintenance. In addition, it is equipped with a diagnostic interface (with EMC filtering), an EEPROM for diagnostic data, and status detection and operation components for the AC800F CPU motherboard.

In summary, the SA801F power module provides a stable and reliable power solution for industrial automation applications with its wide input range, efficient output, multiple protections, status monitoring, easy integration, and rich additional functions.
