ABB AI815 模拟量输入模块 是一款功能强大、性能稳定、易于安装和维护的模拟量输入模块,广泛应用于工业自动化领域,如温度、压力等需要高精度模拟量输入输出的场景。
ABB AI815 模拟量输入模块 详情介绍:
AI815模拟量输入模块是一款功能强大的产品,其主要特点和功能如下:
- 信号类型:AI815模拟量输入模块可以配置为电压或电流输入,但需要注意的是,电流和电压信号不能在同一I/O模块上混合使用。
- 输入电阻:电压输入的输入电阻大于10M欧姆,而电流输入的输入电阻为250欧姆。
- 电源供应:模块能够将外部HART兼容变送器电源分配给每个通道,这为2线制或3线制变送器的供电分配提供了一个简单的连接。同时,模块会监控并限制发射机电源的电流。
- HART通讯:AI815模块支持HART通讯协议,并具有HART直通功能,仅支持点对点通信。
- 隔离与分组:该模块具有分组与地面隔离的功能,提高了系统的安全性和稳定性。1组8通道与地隔离。
- 分辨率:模块的分辨率为12位,能够提供高精度的模拟信号测量。
- 温度范围:AI815模拟量输入模块具有宽温度范围,可以在恶劣的环境条件下稳定运行。
- 模块化结构:模块化设计使得该模块可以根据用户的需求不断地进行扩展,满足不同的安装需求,如小规模或大规模、户内或户外、墙面安装或地面固定。
- 节省成本:AI815模拟量输入模块可以现场安装,靠近传感器和执行器,这样可以减少接线成本,帮助用户节省硬件、电缆、安装和维护的费用。
- 高可靠性:模块具有良好的抗振性,支持热插拔功能,并具有自诊断、冗余等特点,确保了其高可靠性。
总的来说,AI815模拟量输入模块是一款功能强大、性能稳定、易于安装和维护的模拟量输入模块,广泛应用于工业自动化领域,如温度、压力等需要高精度模拟量输入输出的场景。
ABB AI815 模拟量输入模块 实物图片:
ABB AI815 模拟量输入模块 实物视频
ABB AI815 Analog Input Module Details Introduction:
The AI815 analog input module is a powerful product with the following main features and functions:
Signal type: The AI815 analog input module can be configured as voltage or current input, but it should be noted that current and voltage signals cannot be mixed on the same I/O module.
Input resistance: The input resistance for voltage input is greater than 10M ohms, while the input resistance for current input is 250 ohms.
Power supply: The module is able to allocate external HART-compatible transmitter power to each channel, providing a simple connection for power distribution of 2-wire or 3-wire transmitters. At the same time, the module will monitor and limit the current of the transmitter power supply.
Hart communication: The AI815 module supports the Hart communication protocol and has a direct through function, only supporting point-to-point communication.
Isolation and Grouping: This module has the function of isolating groups from the ground, which improves the security and stability of the system. 1 set of 8 channels isolated from the ground.
Resolution: The resolution of the module is 12 bits, which can provide high-precision analog signal measurement.
Temperature range: The AI815 analog input module has a wide temperature range and can operate stably under harsh environmental conditions.
Modular structure: Modular design allows the module to continuously expand according to user needs, meeting different installation needs, such as small-scale or large-scale, indoor or outdoor, wall installation or ground fixation.
Cost saving: The AI815 analog input module can be installed on-site, close to sensors and actuators, which can reduce wiring costs and help users save hardware, cable, installation, and maintenance costs.
High reliability: The module has good vibration resistance, supports hot swapping function, and features self diagnosis, redundancy, etc., ensuring its high reliability.
Overall, the AI815 analog input module is a powerful, stable, easy to install and maintain analog input module, widely used in industrial automation fields, such as temperature, pressure, and other scenarios that require high-precision analog input and output.
