ABB SPDSO14 数字输出模块 是ABB公司生产的一款产品，主要用于现场控制单元的硬件配置，完成插件的配置（如主机插件、电源插件、I/O插件、通信插件等）、硬件冗余配置、硬件安装等任务
ABB SPDSO14 数字输出模块 详情介绍：
SPDSO14数字输出模块是ABB公司生产的一款产品，主要用于现场控制单元的硬件配置，完成插件的配置（如主机插件、电源插件、I/O插件、通信插件等）、硬件冗余配置、硬件安装等任务。以下是关于SPDSO14数字输出模块的详细信息：
- 产品特性：
- 作为一种模拟输出模件，它可以输出各种模拟信号，如电压、电流等。
- SPDSO14提供了控制器和I/O模块之间的路径，通过ASI模块与控制器进行通信，实现输入和输出数据的传输。
- 该模块支持16个数字输出通道（DO），具有开路集电极类型。
- 它的输入暂存器反映输入信号状态，输出点反映输出锁存器状态。
- 应用场景：
- SPDSO14数字输出模块通常用于工业自动化控制系统，如Symphony Plus I/O HR系列（Harmony Rack）等。
- 它可以在Harmony控制单元（HCU）内作为子系统的一部分，与控制子系统和其他I/O子系统协同工作。
- 技术参数：
- 产品净深/长：73.66 mm
- 产品净高：360.68 mm
- 产品净宽：279.4 mm
- 产品净重：0 kg
- 环保WEEE类别：5（小型设备，外部尺寸不超过50厘米）
ABB SPDSO14 数字输出模块 实物图片：
ABB SPDSO14 数字输出模块 实物视频
ABB SPDSO14 Digital Output Module Details Introduction:
The SPDSO14 digital output module is a product produced by ABB, mainly used for hardware configuration of on-site control units, completing tasks such as configuring plugins (such as host plugins, power plugins, I/O plugins, communication plugins, etc.), hardware redundancy configuration, hardware installation, etc. The following is detailed information about the SPDSO14 digital output module:
Product features:
As an analog output module, it can output various analog signals, such as voltage, current, etc.
SPDSO14 provides a path between the controller and the I/O module, which communicates with the controller through the ASI module to achieve the transmission of input and output data.
This module supports 16 digital output channels (DO) and has an open collector type.
Its input register reflects the state of the input signal, and its output point reflects the state of the output latch.
Application scenario:
SPDSO14 digital output modules are commonly used in industrial automation control systems, such as Symphony Plus I/O HR series (Harmony Rack), etc.
It can function as part of a subsystem within the Harmony Control Unit (HCU), working in conjunction with the control subsystem and other I/O subsystems.
Technical parameters:
Product net depth/length: 73.66 mm
Product net height: 360.68 mm
Product net width: 279.4 mm
Net weight of product: 0 kg
Environmental WEEE category: 5 (small equipment, external dimensions not exceeding 50 centimeters)
