REL551 1MRK002480-AE线路差动保护装置是配电、变电站和输电线路差动保护应用的基本单元，是PANORAMA变电站自动化的一部分。
REL551 1MRK002480-AE线路差动保护装置产品图片展示：
REL551 1MRK002480-AE线路差动保护装置实物产品拍摄视频：
REL551 1MRK002480-AE线路差动保护装置产品详情说明：
线路差动功能包括：- 分相电流微分幅值和相位角的测量- 通过CT饱和检测器提高稳定性- 传输延迟的连续补偿， 能够使用路由交换通信网络- 数字通信信道内的转移跳闸- 主/主设计- 用于多路连接、直接光纤或导频线的接口• 附加保护功能，如：-相位和剩余电流函数- 断路器故障保护&二进制信号的快速通道间通信- 电流电路监控-单极或多极跳闸• 控制指挥控制-自动重合闸•监控- 事件记录器-干扰记录器 | Line differential functionality comprises;- phase segregated current differentialmeasurement evaluating both magnitude and phase angle- increased stabilisation through CT saturation detector- continuous compensation of transmission delay, enabling use of routeswitched communicationnetworks- transfer trip within the digital communication channel- master/master design- interfaces for multiplexed connections,direct fibre or pilot wires• Additional protection functionality such as;-phase and residual current functions- breaker failure protection- fast interbay communication of binarysignals- current circuit supervision- single-or multi-pole tripping• Control;- command control- autoreclosing• Monitoring;- event recorder- disturbance recorder |
应用电流差动保护比较进入和离开受保护的架空线路或电缆的电流。需要一个可靠的通信设施，以便在线路末端的终端之间进行信息交换。该差动功能为输电、输电和配电网络提供分相真电流差动保护。它在所有方面都是一个数字系统，用于现代数字通信系统，包括多路复用和路由交换系统。电流在每相的基础上进行比较，避免了电流求和方法的问题，并为单极跳闸提供了相位选择信息。
ApplicationCurrent differential protection compares thecurrents entering and leaving a protectedoverhead line or cable. A dependable communication facility is needed to allow information exchange between the terminals at theline ends.This differential function offers phase-segregated true current differential protection fortransmission, sub-transmission and distribution networks. It is in all a numerical systemfor use with modern digital communicationsystems including multiplexed and routeswitched systems. Currents are compared ona per phase basis, obviating the problem ofthe current summation approach and providing phase selection information for singlepole tripping.
