SCHNEIDER ATV71HD22N4 变速驱动模块

SCHNEIDER ATV71HD22N4 变速驱动模块

1.产 品 资 料 介 绍：

中文资料：

SCHNEIDER ATV71HD22N4 变速驱动模块 是施耐德电气（Schneider Electric）推出的一款变频驱动器，专为控制交流电动机的速度和转矩而设计。它广泛应用于各种工业自动化和机械设备控制中，能够有效提升能源利用效率、优化设备运行，并支持多个控制功能。

产品概述

1. 功能描述

   • 变频控制：ATV71HD22N4 变频驱动器提供对交流电动机的精准调速控制，广泛应用于泵、风机、输送机、压缩机等机械设备的驱动控制。
   • 节能性能：通过调节电动机的运行速度，ATV71HD22N4 有效减少能源消耗，尤其适用于负载变化较大的场合，如风机和泵类设备。
   • 多种控制方式：支持多种控制模式，包括转矩控制、速度控制和闭环控制等，满足不同应用需求。

2. 应用领域

   • 工业自动化：适用于各种工业设备，如水处理、HVAC（暖通空调）、包装、纺织等领域的动力驱动系统。
   • 电动机控制：为电动机提供高效、精确的速度和转矩控制，确保设备平稳高效运行。
   • 能源管理：在节能和能源优化方面，尤其是对电动机负载波动较大的场景，表现出色。

技术规格

英文资料：

The SCHNEIDER ATV71HD22N4 variable speed drive module is a variable frequency drive developed by Schneider Electric, specifically designed to control the speed and torque of AC motors. It is widely used in various industrial automation and mechanical equipment control, which can effectively improve energy utilization efficiency, optimize equipment operation, and support multiple control functions.

Product Overview

Function Description

Variable frequency control: The ATV71HD22N4 variable frequency drive provides precise speed control for AC motors and is widely used in the drive control of mechanical equipment such as pumps, fans, conveyors, compressors, etc.

Energy saving performance: By adjusting the operating speed of the motor, ATV71HD22N4 effectively reduces energy consumption, especially suitable for situations with large load changes, such as fans and pumps.

Multiple control modes: Supports multiple control modes, including torque control, speed control, and closed-loop control, to meet different application requirements.

application area

Industrial automation: Suitable for power drive systems in various industrial equipment fields such as water treatment, HVAC (Heating, Ventilation and Air Conditioning), packaging, textiles, etc.

Electric motor control: provides efficient and precise speed and torque control for electric motors, ensuring smooth and efficient operation of equipment.

Energy management: Excellent performance in energy conservation and optimization, especially in scenarios with large fluctuations in motor load.

technical specifications

Parameter specification description

Model ATV71HD22N4

Voltage type: AC voltage 380V -480V

Power range 11kW (15 HP)

Input voltage 380V -480V, 3-phase AC current

The output voltage is consistent with the input voltage

Frequency range 0-590 Hz

Control method vector control (V/f control, closed-loop vector control, open-loop vector control)

Communication protocols include Modbus RTU, Profibus DP, Ethernet/IP, CANopen, etc

Environmental temperature range -10 ° C to+50 ° C

Phase number three-phase power supply

Display interface LED display panel, supporting keyboard input

Overload capacity 150% rated current, 1 minute

The size is approximately 380 x 260 x 240 mm (the specific size may vary slightly depending on the specific model)

Protection functions include overload protection, overcurrent protection, overheating protection, dust prevention, waterproofing, etc
