SYCHROTACT 5 3BHB006716R0277 自动同步器

ABB SYCHROTACT 5  3BHB006716R0277 自动同步器

1.产 品 资 料 介 绍：

中文资料：

SYCHROTACT 5 3BHB006716R0277 是 ABB 生产的一款 自动同步器，用于同步发电机与电网或母线，确保安全、精确的并网操作。它在电力系统中扮演关键角色，特别适用于发电厂、工业电网和分布式能源系统。

1. 产品概述

• 产品型号：SYCHROTACT 5 3BHB006716R0277
• 制造商：ABB
• 设备类型：自动同步器（Automatic Synchronizer）
• 应用场景：同步发电机与电网，确保安全、精准并网

2. 主要特点

• 高精度同步：

  • 实时测量 电压、频率、相角，确保并网精度
  • 具备可调同步参数，提高系统适应性

• 自动化控制：

  • 可自动执行并网过程，减少人为干预，提高安全性
  • 具备手动/自动两种工作模式

• 兼容性强：

  • 适用于不同类型的发电机（同步发电机、异步发电机等）
  • 可兼容多种电力系统架构

• 内置保护功能：

  • 具备过压、欠压、过频、欠频、相序错误等多种保护功能
  • 避免误操作导致的设备损坏

• 通信与接口：

  • 支持 Modbus、IEC 61850 等工业通信协议（具体型号支持情况需确认）
  • 具备 RS-485、以太网 等数据接口，便于远程监控

英文资料：

SYCHROTACT 5 3BHB006716R0277 is an automatic synchronizer produced by ABB, used to synchronize generators with the grid or busbar, ensuring safe and accurate grid connection operations. It plays a crucial role in the power system, particularly suitable for power plants, industrial grids, and distributed energy systems.

1. Product Overview

Product model: SYCHROTACT 5 3BHB006716R0277

manufacturer: ABB

Equipment type: Automatic Synchronizer

Application scenario: Synchronize generators with the power grid to ensure safe and accurate grid connection

2. Main features

High precision synchronization:

Real time measurement of voltage, frequency, and phase angle to ensure grid accuracy

Equipped with adjustable synchronization parameters to improve system adaptability

Automated control:

Automatically execute the grid connection process, reduce human intervention, and improve safety

Equipped with manual/automatic working modes

Strong compatibility:

Suitable for different types of generators (synchronous generators, asynchronous generators, etc.)

Compatible with multiple power system architectures

Built in protection function:

It has multiple protection functions such as overvoltage, undervoltage, overclocking, underfrequency, and phase sequence error

Prevent equipment damage caused by misoperation

Communication and Interface:

Supports industrial communication protocols such as Modbus and IEC 61850 (specific model support needs to be confirmed)

Equipped with RS-485, Ethernet and other data interfaces for remote monitoring

2.产      品      展      示
