LXN1604-6 3BHL000986P7000功率转换器

ABB LXN1604-6 3BHL000986P7000功率转换器

1.产 品 资 料 介 绍：

中文资料：

LXN1604-6 3BHL000986P7000 是ABB公司生产的一款功率转换器（Power Converter），主要用于工业驱动、可再生能源或电力电子系统，实现高效电能转换与控制。以下是详细技术分析：

1. 产品基本信息

• 型号：LXN1604-6（产品系列+规格代码）

• 订货号：3BHL000986P7000（ABB唯一标识）

• 品牌：ABB（全球电力和自动化领先厂商）

• 类型：功率转换器（可能属于 ACS880、PCS100 或 Wind Power Converter 系列）

• 用途：交/直流转换、变频驱动、能量回馈

2. 核心功能

✅ AC/DC或DC/AC转换（如风电变流器、光伏逆变器）
✅ 电机驱动控制（用于工业变频调速）
✅ 再生制动能量回馈（节能应用）
✅ 电网谐波抑制（低THD设计，符合IEEE 519标准）
✅ 多协议通信（支持Profibus、Modbus TCP、CANopen等）

3. 典型应用领域

(1) 工业变频驱动（如ABB ACS880系列）

• 用于大型电机（泵、风机、压缩机）的节能调速

• 高动态响应，适用于轧钢机、起重机等重载应用

(2) 可再生能源（风电/光伏）

• 风电变流器：双馈或全功率风电机组的并网控制

• 光伏逆变器：DC→AC转换，支持MPPT（最大功率点跟踪）

(3) 轨道交通与船舶

• 牵引系统（地铁、高铁）的直流供电转换

• 船舶电力推进系统的变频驱动

(4) 微电网与储能

• 电池储能系统（BESS）的PCS（功率转换系统）

• 黑启动、孤岛模式下的电能管理

英文资料：

LXN1604-6 3BHL000986P7000 is a power converter produced by ABB, mainly used in industrial drives, renewable energy or power electronics systems to achieve efficient energy conversion and control. The following is a detailed technical analysis:

1. Basic product information

Model: LXN1604-6 (Product Series+Specification Code)

Order number: 3BHL000986P7000 (ABB unique identifier)

Brand: ABB (global leader in power and automation)

Type: Power Converter (may belong to ACS880, PCS100, or Wind Power Converter series)

Usage: AC/DC conversion, variable frequency drive, energy feedback

2. Core functions

✅  AC/DC or DC/AC conversion (such as wind power converters, photovoltaic inverters)

✅  Motor drive control (for industrial variable frequency speed regulation)

✅  Regenerative braking energy feedback (energy-saving application)

✅  Grid harmonic suppression (low THD design, compliant with IEEE 519 standard)

✅  Multi protocol communication (supporting Profibus, Modbus TCP, CANopen, etc.)

3. Typical application areas

(1) Industrial variable frequency drive (such as ABB ACS880 series)

Energy saving speed regulation for large motors (pumps, fans, compressors)

High dynamic response, suitable for heavy-duty applications such as rolling mills and cranes

(2) Renewable energy (wind/photovoltaic)

Wind power converter: grid connected control of doubly fed or full power wind turbines

Photovoltaic inverter: DC to AC conversion, supports MPPT (maximum power point tracking)

(3) Rail Transit and Ships

DC power conversion for traction systems (subway, high-speed rail)

Variable frequency drive for ship electric propulsion system

(4) Microgrid and Energy Storage

PCS (Power Conversion System) of Battery Energy Storage System (BESS)

Electric energy management in black start and islanding mode

2.产      品      展      示
