ABB OS63D12熔断开关
1.产 品 资 料 介 绍：
中文资料：
OS63D12 是一款由 Schneider Electric（施耐德电气）公司生产的 熔断开关，通常用于电力系统和电气设备中的保护和断电功能。熔断开关在电气系统中起到关键的保护作用，能够有效避免过载、短路等故障对设备和电路的损害。
主要特点
高短路开断能力：OS63D12 熔断开关具有较高的短路开断能力，能够快速切断电路中可能发生的高电流短路故障，避免设备损坏。
保护作用：该熔断开关的主要功能是为电路中的负载提供过载和短路保护。当电流超过安全阈值时，熔断开关会自动切断电路，防止过载电流对电气设备造成损害。
可更换熔断器：该开关配备了可更换的熔断器元件，当熔断器熔断时，用户只需更换熔断器，而无需更换整个开关。
耐用性：OS63D12 采用优质材料，具有较强的耐用性和稳定性，能够承受长期高负荷运行并在极端条件下保持良好性能。
简便的操作和维护：熔断开关结构简单，易于安装和维护，适合各类工业和商业电气系统。
技术规格
额定电流：OS63D12 的额定电流通常为 63A，适用于中小型电气系统中的负载保护。
额定电压：适用于 400V 或更低电压的交流电路，确保在正常工作电压下安全运行。
短路开断能力：该熔断开关的额定短路开断能力较高，通常为 10 kA 或 12.5 kA，能够应对工业电气系统中常见的短路故障。
熔断器类型：该开关使用的熔断器是可替换的类型，确保在发生熔断时，用户可以方便地更换，而无需更换整个装置。
尺寸和安装方式：符合标准 DIN rail 安装方式，便于与其他设备一起安装，并节省配电箱空间。
英文资料：
OS63D12 is a fuse switch produced by Schneider Electric, commonly used for protection and power-off functions in power systems and electrical equipment. Fuse switches play a critical protective role in electrical systems, effectively avoiding damage to equipment and circuits caused by overload, short circuits, and other faults.
main features
High short-circuit breaking capacity: OS63D12 fuse switch has high short-circuit breaking capacity, which can quickly cut off high current short-circuit faults that may occur in the circuit and avoid equipment damage.
Protection function: The main function of this fuse switch is to provide overload and short-circuit protection for the load in the circuit. When the current exceeds the safety threshold, the fuse switch will automatically cut off the circuit to prevent damage to electrical equipment caused by overload current.
Interchangeable fuse: This switch is equipped with replaceable fuse components. When the fuse is blown, users only need to ｒｅｐｌａｃｅ the fuse, without having to ｒｅｐｌａｃｅ the entire switch.
Durability: OS63D12 is made of high-quality materials with strong durability and stability, capable of withstanding long-term high load operation and maintaining good performance under extreme conditions.
Easy operation and maintenance: The fuse switch has a simple structure, is easy to install and maintain, and is suitable for various industrial and commercial electrical systems.
technical specifications
Rated current: The rated current of OS63D12 is usually 63A, suitable for load protection in small and medium-sized electrical systems.
Rated voltage: Suitable for AC circuits with 400V or lower voltage, ensuring safe operation at normal operating voltage.
Short circuit breaking capacity: The rated short circuit breaking capacity of this fuse switch is relatively high, usually 10 kA or 12.5 kA, which can cope with common short circuit faults in industrial electrical systems.
Fuse type: The fuse used in this switch is of a replaceable type, ensuring that in the event of a fuse failure, users can easily ｒｅｐｌａｃｅ it without having to ｒｅｐｌａｃｅ the entire device.
Size and installation method: Complies with the standard DIN rail installation method, making it easy to install with other equipment and saving space in the distribution box.
2.产 品 展 示
