FN2010-60-24过滤器

ABB  FN2010-60-24过滤器

1.产 品 资 料 介 绍：

中文资料：

FN2010-60-24 是一款由 Schaffner（夏夫纳）公司生产的 电源滤波器，通常用于减少电力系统中的电磁干扰（EMI）并确保设备的稳定运行。该过滤器能够有效地保护电子设备免受噪声和干扰的影响，提高电气系统的性能和可靠性。

主要特点

• 高效滤波：FN2010-60-24 设计用于有效地减少来自电网或电气设备的高频电磁干扰（EMI），提高设备的抗干扰能力。

• 适用广泛：该滤波器适用于交流电源系统，能够处理 50Hz 或 60Hz 的电网频率，广泛应用于工业和商业设备中。

• 紧凑设计：具有紧凑的外形和高效能，便于安装在各种电气配电系统中，特别是在有限空间的设备中。

• 高电流容量：FN2010-60-24 能够处理 60 A 的额定电流，适合中等规模设备和系统的使用。

• 优良的性能：该过滤器具有优秀的电压耐受性和滤波效果，能够有效地减少噪声，降低干扰，确保设备运行稳定。

• 抗高温和可靠性：具有较强的热稳定性，可以在宽温范围内稳定运行，适应严苛的工作环境。

技术规格

• 额定电流：60 A，适用于中等负载的电气系统。

• 额定电压：通常为 250V AC，适用于交流电源。

• 频率范围：适用于 50/60 Hz 电源系统，确保广泛的兼容性。

• 滤波性能：FN2010-60-24 设计用于有效地抑制高频电磁干扰，符合 CISPR 22 和 EN 55022 等国际标准。

• 工作温度范围：一般为 -25°C 到 85°C，确保在多种工作环境下的可靠性。

• 安装方式：通常使用标准的 DIN rail 安装方式，便于与其他设备一同安装，并节省空间。

英文资料：

FN2010-60-24 is a power filter produced by Schaffner, commonly used to reduce electromagnetic interference (EMI) in power systems and ensure stable operation of equipment. This filter can effectively protect electronic devices from noise and interference, improving the performance and reliability of electrical systems.

main features

Efficient filtering: FN2010-60-24 is designed to effectively reduce high-frequency electromagnetic interference (EMI) from the power grid or electrical equipment, and improve the anti-interference ability of the equipment.

Widely applicable: This filter is suitable for AC power systems and can handle grid frequencies of 50Hz or 60Hz. It is widely used in industrial and commercial equipment.

Compact design: With a compact appearance and high efficiency, it is easy to install in various electrical distribution systems, especially in equipment with limited space.

High current capacity: FN2010-60-24 can handle a rated current of 60 A, suitable for use in medium-sized equipment and systems.

Excellent performance: This filter has excellent voltage tolerance and filtering effect, which can effectively reduce noise, minimize interference, and ensure stable equipment operation.

High temperature resistance and reliability: With strong thermal stability, it can operate stably over a wide temperature range and adapt to harsh working environments.

technical specifications

Rated current: 60 A, suitable for electrical systems with moderate loads.

Rated voltage: usually 250V AC, suitable for AC power supply.

Frequency range: Suitable for 50/60 Hz power systems, ensuring wide compatibility.

Filtering performance: FN2010-60-24 is designed to effectively suppress high-frequency electromagnetic interference and complies with international standards such as CISPR 22 and EN 55022.

Working temperature range: generally from -25 ° C to 85 ° C, ensuring reliability in various working environments.

Installation method: The standard DIN rail installation method is usually used, which facilitates installation with other devices and saves space.

2.产      品      展      示
