ABB DO820数字输出继电器模块
1.产 品 资 料 介 绍:
中文资料:
DO820 是 ABB 生产的一款 数字输出继电器模块,用于工业自动化和过程控制系统。它适用于 AC 230V 或 DC 24V 负载,能够驱动电磁阀、继电器和其他执行设备。
主要特点
16个数字输出,每个通道都具备高负载能力。
继电器隔离,提供更高的电气安全性。
支持高电压负载,适用于 AC 230V 和 DC 24V 设备。
模块化设计,兼容 ABB S800 I/O 系列,易于集成。
LED状态指示,便于诊断和维护。
技术规格
输出通道:16个继电器输出。
额定电压:AC 230V / DC 24V。
最大输出电流:2A/通道。
响应时间:<10ms,确保快速切换。
安装方式:DIN导轨 或 机架安装。
应用领域
过程控制:适用于工厂自动化和工业控制系统。
电力系统:用于控制断路器、继电器和警报系统。
楼宇自动化:用于照明、空调和其他楼宇控制系统。
DO820 具有高电压兼容性、继电器隔离保护,是工业控制和自动化系统中的可靠选择。
英文资料:
DO820 is a digital output relay module produced by ABB, used in industrial automation and process control systems. It is suitable for AC 230V or DC 24V loads and can drive solenoid valves, relays, and other actuating devices.
main features
16 digital outputs, each channel has high load capacity.
Relay isolation provides higher electrical safety.
Supports high voltage loads and is suitable for AC 230V and DC 24V devices.
Modular design, compatible with ABB S800 I/O series, easy to integrate.
LED status indicator for easy diagnosis and maintenance.
technical specifications
Output channel: 16 relay outputs.
Rated voltage: AC 230V / DC 24V。
Maximum output current: 2A/channel.
Response time:< 10ms, ensure fast switching.
Installation method: DIN rail or rack installation.
application area
Process control: suitable for factory automation and industrial control systems.
Power system: used to control circuit breakers, relays, and alarm systems.
Building automation: used for lighting, air conditioning, and other building control systems.
DO820 has high voltage compatibility and relay isolation protection, making it a reliable choice in industrial control and automation systems.
2.产 品 展 示
