AI810模拟输入模块

发布时间:2025-04-01人气:
  • AI810模拟输入模块
  • AI810模拟输入模块
  • AI810模拟输入模块

ABB  AI810模拟输入模块

1.产 品 资 料 介 绍:

中文资料:

AI810ABB 生产的 模拟输入模块,属于 S800 I/O 系列,用于过程自动化和工业控制系统中的模拟信号采集。该模块能够处理 电流(mA)或电压(V) 信号,广泛应用于传感器、变送器等设备的数据采集。


主要特点

  • 8个模拟输入通道,支持多种信号类型。

  • 支持电流/电压输入,适用于各种工业传感器。

  • 高精度A/D转换,确保数据采集的准确性。

  • 故障检测功能,包括断线检测,提高系统可靠性。

  • 兼容ABB S800 I/O系统,易于集成到AC 800M等DCS控制系统。


技术规格

  • 输入类型

    • 电压模式:±10V

    • 电流模式:0/4-20mA

  • 通道数:8个独立输入通道

  • 分辨率:12位 A/D 转换

  • 扫描时间2ms/通道,支持快速数据更新

  • 安装方式:DIN导轨或机架安装

  • 隔离保护:通道与系统之间电气隔离,提高抗干扰能力

英文资料:

AI810 is an analog input module produced by ABB, belonging to the S800 I/O series, used for analog signal acquisition in process automation and industrial control systems. This module is capable of processing current (mA) or voltage (V) signals and is widely used for data acquisition in devices such as sensors and transmitters.


main features

8 analog input channels, supporting multiple signal types.


Supports current/voltage input and is suitable for various industrial sensors.


High precision A/D conversion ensures the accuracy of data acquisition.


Fault detection function, including wire breakage detection, improves system reliability.


Compatible with ABB S800 I/O system, easy to integrate into DCS control systems such as AC 800M.


technical specifications

Input type:


Voltage mode: ± 10V


Current mode: 0/4-20mA


Number of channels: 8 independent input channels


Resolution: 12 bit A/D conversion


Scanning time: 2ms/channel, supports fast data updates


Installation method: DIN rail or rack installation


Isolation protection: Electrical isolation between channels and systems to improve anti-interference ability

2.产      品      展      示
