DILA-22继电器

发布时间:2025-04-01人气:
  • DILA-22继电器
  • DILA-22继电器
  • DILA-22继电器

ABB  DILA-22继电器

1.产 品 资 料 介 绍:

中文资料:

DILA-22Eaton(伊顿) 生产的一款 辅助继电器/接触器,用于控制辅助电路中的信号切换和远程控制。它通常与主接触器或继电器配合使用,广泛应用于工业自动化、电力系统和机械控制领域。


主要特点

  • 辅助触点配置2常开(NO)+ 2常闭(NC),适用于多种控制需求。

  • 高可靠性:触点采用耐磨材料,确保长期稳定运行。

  • 模块化设计:可与 DIL 系列主接触器兼容,易于扩展。

  • 紧凑结构:支持 DIN 导轨安装,节省空间。

  • 高机械耐久性:额定寿命高,适用于频繁操作的场合。


技术规格

  • 额定电压24V、110V、230V AC/DC(视具体型号而定)。

  • 额定电流10A(适用于低功率控制电路)。

  • 触点配置:2NO + 2NC。

  • 安装方式DIN导轨螺钉固定

  • 工作温度范围:-25°C 至 +55°C,适应恶劣环境。


应用领域

  • 工业自动化:用于PLC、继电器控制系统的辅助信号切换。

  • 电力控制系统:用于变电站、配电柜中的状态指示和信号传输。

  • 机械设备:控制电机、报警装置、照明系统等。


DILA-22 继电器结构紧凑、性能稳定,是工业和商业电控系统中常见的辅助控制组件。

英文资料:

DILA-22 is an auxiliary relay/contactor produced by Eaton, used for controlling signal switching and remote control in auxiliary circuits. It is usually used in conjunction with main contactors or relays and is widely used in industrial automation, power systems, and mechanical control fields.


main features

Auxiliary contact configuration: 2 normally open (NO)+2 normally closed (NC), suitable for various control requirements.


High reliability: The contacts are made of wear-resistant materials to ensure long-term stable operation.


Modular design: compatible with DIL series main contactors and easy to expand.


Compact structure: Supports DIN rail installation, saving space.


High mechanical durability: With a high rated lifespan, it is suitable for frequent operations.


technical specifications

Rated voltage: 24V, 110V, 230V AC/DC (depending on the specific model).


Rated current: 10A (suitable for low-power control circuits).


Contact configuration: 2NO+2NC.


Installation method: DIN rail or screw fixation.


Working temperature range:- 25 ° C to+55 ° C, suitable for harsh environments.


application area

Industrial automation: Used for auxiliary signal switching in PLC and relay control systems.


Power control system: used for status indication and signal transmission in substations and distribution cabinets.


Mechanical equipment: control motors, alarm devices, lighting systems, etc.


DILA-22 relay has a compact structure and stable performance, and is a common auxiliary control component in industrial and commercial electronic control systems.
