ABB DILA-XH11接触器
1.产 品 资 料 介 绍:
中文资料:
DILA-XH11 是 Eaton(伊顿) 生产的一款 辅助接触器模块,主要用于扩展 DILA 系列接触器的功能。它增加了 1个常开(NO)+ 1个常闭(NC) 触点,可用于信号控制、状态指示和电路逻辑转换。
主要特点
1NO + 1NC 触点配置,适用于不同的控制需求。
可直接安装在 DILA 接触器上,无需额外布线,扩展便捷。
高耐久性触点,确保长期可靠运行。
模块化设计,兼容 DILM/DILA 系列主接触器。
支持 DIN 导轨安装,方便集成到控制柜中。
技术规格
触点配置:1NO + 1NC(常开+常闭)。
额定电流:10A。
额定电压:AC/DC 24V、110V、230V(视具体型号而定)。
机械寿命:超 1000万次 操作。
工作温度:-25°C 至 +55°C。
安装方式:直接插接到 DILA 接触器上,或安装在 DIN 导轨上。
应用领域
工业自动化:用于 PLC 和继电器控制系统的辅助功能扩展。
电力系统:信号切换、状态指示和电路逻辑控制。
机械设备:与主接触器配合使用,实现电机或其他设备的逻辑控制。
DILA-XH11 结构紧凑、安装便捷,是 DILA 系列接触器 的理想扩展模块,在工业自动化和电气控制系统中广泛应用。
英文资料:
DILA-XH11 is an auxiliary contactor module produced by Eaton, mainly used to expand the functionality of the DILA series contactors. It adds one normally open (NO) and one normally closed (NC) contact, which can be used for signal control, status indication, and circuit logic conversion.
main features
1NO+1NC contact configuration, suitable for different control requirements.
It can be directly installed on the DILA contactor without additional wiring, making expansion convenient.
High durability contacts ensure long-term reliable operation.
Modular design, compatible with DILM/DILA series main contactors.
Supports DIN rail installation for easy integration into control cabinets.
technical specifications
Contact configuration: 1NO+1NC (normally open+normally closed).
Rated current: 10A.
Rated voltage: AC/DC 24V, 110V, 230V (depending on the specific model).
Mechanical lifespan: over 10 million operations.
Working temperature:- 25 ° C to+55 ° C.
Installation method: directly plug into the DILA contactor or install on a DIN rail.
application area
Industrial automation: Used for auxiliary function expansion of PLC and relay control systems.
Power system: signal switching, status indication, and circuit logic control.
Mechanical equipment: Used in conjunction with the main contactor to achieve logical control of motors or other equipment.
DILA-XH11 has a compact structure and easy installation, making it an ideal expansion module for DILA series contactors, widely used in industrial automation and electrical control systems.
2.产 品 展 示
