BENTLY 3500/32 125720-01中继模块

BENTLY 3500/32 125720-01中继模块

1.产 品 资 料 介 绍：

中文资料：

Bently Nevada 3500/32 125720-01 是一款 4通道继电器 I/O 模块，专为 Bently Nevada 3500 系列机械监测系统设计。该模块提供四个独立的继电器输出，可用于控制外部设备，如报警器、阀门或泵。

主要特点：

• 模块化设计：作为全高模块，可安装在机架接口模块右侧的任意插槽中，支持多模块配置。
• 可编程功能：每个继电器可独立编程，执行投票逻辑，满足不同应用需求。
• 报警驱动逻辑：支持 AND 和 OR 逻辑编程，可结合任意监控通道或报警输入，实现复杂的报警驱动。
• 高可靠性：采用优质元件制造，确保长期稳定运行。

技术规格：

• 继电器类型：单刀双掷（SPDT）
• 触点额定值：在 24 VDC 下为 5 A，在 240 VAC 下为 5 A
• 功耗：典型值为 5.8 瓦
• 工作温度：-30°C 至 +65°C
• 存储温度：-40°C 至 +85°C
• 湿度：95%，无冷凝
• 尺寸：主模块：241 mm x 24.4 mm x 242 mm；I/O 模块：241 mm x 24.4 mm x 99.1 mm
• 重量：主模块约 0.7 kg

应用领域：

• 报警系统：在检测到异常情况时，触发报警器。
• 设备控制：控制外部设备，如阀门或泵。
• 联锁保护：提供联锁功能，防止危险操作。

英文资料：

Bently Nevada 3500/32 125720-01 is a 4-channel relay I/O module designed specifically for Bently Nevada 3500 series mechanical monitoring systems. This module provides four independent relay outputs that can be used to control external devices such as alarms, valves, or pumps.

Main features:

Modular design: As a full height module, it can be installed in any slot on the right side of the rack interface module and supports multi module configuration.

Programmable function: Each relay can be independently programmed to execute voting logic, meeting different application requirements.

Alarm driver logic: Supports AND and OR logic programming, and can be combined with any monitoring channel or alarm input to achieve complex alarm driving.

High reliability: Made with high-quality components to ensure long-term stable operation.

Technical specifications:

Relay type: Single pole double throw (SPDT)

Contact rating: 5 A at 24 VDC and 5 A at 240 VAC

Power consumption: Typical value is 5.8 watts

Working temperature:- 30 ° C to+65 ° C

Storage temperature:- 40 ° C to+85 ° C

Humidity: 95%, no condensation

Size: Main module: 241 mm x 24.4 mm x 242 mm; I/O module: 241 mm x 24.4 mm x 99.1 mm

Weight: The main module weighs approximately 0.7 kg

Application areas:

Alarm system: When an abnormal situation is detected, the alarm is triggered.

Equipment control: Control external devices such as valves or pumps.

Interlocking protection: Provides interlocking function to prevent dangerous operations.

2.产      品      展      示
