GE DS200FCGDH1B 输出输入模块

发布时间:2024-02-28人气:
  • GE DS200FCGDH1B 输出输入模块
  • GE DS200FCGDH1B 输出输入模块
  • GE DS200FCGDH1B 输出输入模块

GE  DS200FCGDH1B 输出输入模块   是一款用于六脉冲相位控制的门分配和状态卡(FCGD)的输出输入模块。这款模块由通用电气为其 Mark V 板系列开发,可以安装在许多 GE 品牌的驱动器中。

GE  DS200FCGDH1B 输出输入模块 详情介绍:

  1. GE DS200FCGDH1B 是一款用于六脉冲相位控制的门分配和状态卡(FCGD)的输出输入模块。这款模块由通用电气为其 Mark V 板系列开发,可以安装在许多 GE 品牌的驱动器中。

  2. DS200FCGDH1B 充当六脉冲相位控制不可逆桥的接口系统。当安装到驱动系统中时,该板对相控不可逆桥系统提供接口。DSPC(数字信号处理卡)将信息中继到该板进行解密,然后信息被解码并从驱动器的 VME 背板反馈回来。

  3. 具体来说,DS200FCGDH1B 接收来自每个桥腿的复用单元状态信号,并对每个桥腿的单元门控信号进行解码和去分配。此外,它还接收桥路反馈信号,对其进行缩放,然后将电压、频率和电流状态数据传送回 DSPC 板。

  4. DS200FCGDH1B 包括一个附加的前面板,具有两个夹子组件,可在模块插入驱动器后将其固定到位。它还具备一个 IMOK LED 状态指示灯,为用户提供基本的系统状态信息。

  5. 这款模块广泛应用于各种工业自动化和控制应用中,包括石油和天然气、电力工业、化工、水处理、制药和制造业等领域。其高可靠性和性能使其成为许多不同应用场景中的理想选择。

  6. 请注意,为确保设备正常运行并降低故障风险,应满足制造商提供的电路板安装参数,并确保正确连接系统。有关 DS200FCGDH1B 的更多信息,包括接线和安装指南,可以在设备手册和数据表中找到。

 GE  DS200FCGDH1B 输出输入模块   实物图片:


GE  DS200FCGDH1B 输出输入模块  实物视频

GE DS200FCGDH1B Output and Input Module Details Introduction:

GE DS200FCGDH1B is an output input module for gate allocation and status card (FCGD) used in six pulse phase control. This module was developed by General Electric for its Mark V board series and can be installed in many GE branded drives.

DS200FCGDH1B serves as the interface system for six pulse phase control irreversible bridge. When installed in the drive system, this board provides an interface to the phase controlled irreversible bridge system. The DSPC (Digital Signal Processing Card) relays information to the board for decryption, and then the information is decoded and fed back from the VME backplane of the driver.

Specifically, DS200FCGDH1B receives multiplexed unit status signals from each bridge leg and decodes and allocates unit gate signals for each bridge leg. In addition, it also receives bridge feedback signals, scales them, and then transmits voltage, frequency, and current status data back to the DSPC board.

DS200FCGDH1B includes an additional front panel with two clamp components that can be secured in place after the module is inserted into the driver. It also has an IMOK LED status indicator, providing users with basic system status information.

This module is widely used in various industrial automation and control applications, including oil and gas, power industry, chemical industry, water treatment, pharmaceuticals, and manufacturing industries. Its high reliability and performance make it an ideal choice for many different application scenarios.

Please note that to ensure the normal operation of the equipment and reduce the risk of malfunctions, the circuit board installation parameters provided by the manufacturer should be met, and the system should be correctly connected. More information about DS200FCGDH1B, including wiring and installation guidelines, can be found in the equipment manual and data sheets.
