HONEYWELL SDOL-0424 数字输出模块

HONEYWELL  SDOL-0424 数字输出模块   是一款功能全面、安全可靠的数字输出模块，适用于各种工业自动化和机器人应用。

HONEYWELL  SDOL-0424 数字输出模块    详情介绍：

Honeywell的SDOL-0424数字输出模块是一款功能强大的安全回路监控数字输出模块，其产品特点包括：

1. 中断和错误处理：该模块支持中断例程和错误处理程序中的动作，这意味着它可以暂时中断一个正在进行的运动，并开始一个独立于第一个运动的新运动。这种功能在机器人应用或其他需要高度控制精度的场合中特别有用。
2. 交叉条件功能：SDOL-0424模块具有数字输入和输出信号的交叉条件功能，类似于PLC的功能。通过输入，可以命令机器人中断程序执行并进入服务位置。当程序执行稍后重新启动（手动或自动）时，机器人将恢复中断的运动。
3. 安全性：在安全性方面，SDOL-0424模块进行了充分的测试，包括断电能力、能够通过二次方式断电、输出之间的串扰、抑制二极管的功能、输出接线中的导线断裂以及输出短路等。这些测试确保了模块在各种条件下的稳定性和可靠性。
4. 通道配置：SDOL-0424有四个24 Vdc，1 A的环路监控输出通道，可驱动高达24 W的负载。最大模块负载为3.6 A。这些负载可以是电阻负载或电感负载。对于感应负载，抑制二极管包括在每个输出上。
5. LED指示：SDOL-0424模块每个通道有一个LED，总共四个。如果某个通道处于关闭状态，则其相应的LED熄灭，并发出短暂的间歇性信号闪烁。这表示正在进行导线断裂试验。
6. 输入电压和功率：输入电压范围为85-264V AC，47-63 Hz或110-370V DC，输出电压为24V DC，输出功率为450 W。
7. 尺寸和重量：产品尺寸为166mm x 112mm x 36mm，重量为1.3公斤。
8. 工作环境：工作温度范围为-40°C至+70°C，适应各种工业环境。

总的来说，Honeywell的SDOL-0424数字输出模块是一款功能全面、安全可靠的数字输出模块，适用于各种工业自动化和机器人应用。

HONEYWELL  SDOL-0424 数字输出模块     实物图片：

HONEYWELL  SDOL-0424 数字输出模块     实物视频

HONEYWELL SDOL-0424 Digital Output Module Details Introduction:

Honeywell's SDOL-0424 digital output module is a powerful safety loop monitoring digital output module, with product features including:

Interrupt and Error Handling: This module supports actions in interrupt routines and error handling programs, which means it can temporarily interrupt an ongoing motion and start a new motion independent of the first motion. This feature is particularly useful in robot applications or other situations that require high control accuracy.

Cross condition function: The SDOL-0424 module has a cross condition function for digital input and output signals, similar to the function of PLC. By entering, the robot can be commanded to interrupt program execution and enter the service position. When the program is restarted later (manually or automatically), the robot will resume interrupted movement.

Security: In terms of security, the SDOL-0424 module has undergone sufficient testing, including power outage capability, ability to power off through secondary means, crosstalk between outputs, diode suppression function, wire breakage in output wiring, and output short circuits. These tests ensure the stability and reliability of the module under various conditions.

Channel configuration: SDOL-0424 has four 24 Vdc, 1 A loop monitoring output channels that can drive loads up to 24 W. The maximum module load is 3.6 A. These loads can be resistive loads or inductive loads. For inductive loads, suppression diodes are included on each output.

LED indication: SDOL-0424 module has one LED per channel, a total of four. If a channel is in a closed state, its corresponding LED will turn off and emit a brief intermittent signal flashing. This indicates that a wire breakage test is currently being conducted.

Input voltage and power: The input voltage range is 85-264V AC, 47-63 Hz or 110-370V DC, the output voltage is 24V DC, and the output power is 450 W.

Size and weight: The product size is 166mm x 112mm x 36mm, with a weight of 1.3 kilograms.

Working environment: The working temperature range is -40 ° C to+70 ° C, suitable for various industrial environments.

Overall, Honeywell's SDOL-0424 digital output module is a comprehensive, safe, and reliable digital output module suitable for various industrial automation and robot applications.
