NI PXIE-5663E多功能 I/O 模块

 NI PXIE-5663E多功能 I/O 模块

1.产 品 资 料 介 绍：

中文资料：

NI PXIe-5663E 是一款高性能的多功能 I/O 模块，专为射频（RF）信号的生成与分析而设计，适用于各种高频应用。以下是它的一些主要特点和应用领域：

主要特点：

• 频率范围： 支持 10 MHz 至 6.6 GHz 的频率范围，能够覆盖广泛的射频应用。
• 即时带宽： 提供高达 50 MHz 的即时带宽，能够捕获并分析高速信号。
• 高分辨率： 采用 16 位分辨率的中频（IF）数字化模块，实现精确的信号测量。
• 模块化设计： PXIe-5663E 结合了射频信号下变频器、数字化模块和射频模拟信号发生器，可以灵活配置满足多种需求。

应用领域：

• 无线通信测试： 广泛用于测试和验证无线通信系统的性能，包括 5G、Wi-Fi 和其他现代通信技术。
• 射频测量： 用于射频信号的测量，如相邻信道泄漏比（ACLR）、谐波分析和杂散测量。
• 信号分析： 可用于复杂射频信号的分析，进行调制解调、信号质量分析等。
• 系统集成： 在综合测试系统中作为关键模块，能够与其他设备协同工作提供全方位的测试解决方案。

技术规格：

• 输入/输出连接： 配备 SMA 母头连接器，支持中频（IF）输入、时钟输入和输出信号连接。
• 功率要求： 需要 +3.3 VDC 电源，RF 信号下变频器功耗为 640 mA，数字化模块功耗为 1.75 A，模拟信号发生器功耗为 1.00 A。
• 工作温度范围： 0°C 至 55°C，适应常见的工业环境。
• 存储温度范围： -40°C 至 71°C，确保在各种严苛条件下的可靠性。

总结而言，NI PXIe-5663E 是一款功能强大的多功能 I/O 模块，广泛适用于无线通信、射频测试、信号分析等多个领域，为现代射频应用提供了高效且精确的解决方案。

英文资料：

NI PXIe-5663E is a high-performance multifunctional I/O module designed specifically for the generation and analysis of radio frequency (RF) signals, suitable for various high-frequency applications. Here are some of its main features and application areas:

Main features:

Frequency range: Supports a frequency range of 10 MHz to 6.6 GHz, capable of covering a wide range of RF applications.

Instant bandwidth: Provides up to 50 MHz of instant bandwidth, capable of capturing and analyzing high-speed signals.

High resolution: Using a 16 bit resolution intermediate frequency (IF) digital module to achieve accurate signal measurement.

Modular design: PXIe-5663E combines RF signal down converter, digital module, and RF analog signal generator, which can be flexibly configured to meet various needs.

Application areas:

Wireless communication testing: widely used to test and verify the performance of wireless communication systems, including 5G, Wi Fi, and other modern communication technologies.

RF measurement: used for measuring RF signals, such as adjacent channel leakage ratio (ACLR), harmonic analysis, and spurious measurement.

Signal analysis: can be used for the analysis of complex RF signals, including modulation and demodulation, signal quality analysis, etc.

System integration: As a key module in the comprehensive testing system, it can collaborate with other devices to provide comprehensive testing solutions.

Technical specifications:

Input/output connection: Equipped with SMA female connector, supporting intermediate frequency (IF) input, clock input, and output signal connection.

Power requirements: A+3.3 VDC power supply is required, the power consumption of the RF signal down converter is 640 mA, the power consumption of the digital module is 1.75 A, and the power consumption of the analog signal generator is 1.00 A.

Working temperature range: 0 ° C to 55 ° C, suitable for common industrial environments.

Storage temperature range:- 40 ° C to 71 ° C ensures reliability under various harsh conditions.

In summary, NI PXIe-5663E is a powerful multifunctional I/O module widely used in various fields such as wireless communication, RF testing, signal analysis, etc., providing efficient and accurate solutions for modern RF applications.
