Zygo 8010-0105-02 ZMI-501 通道隔离板

Zygo 8010-0105-02 ZMI-501 通道隔离板

1.产 品 资 料 介 绍：

中文资料：

Zygo 8010-0105-02 ZMI-501 通道隔离板是 Zygo 公司提供的一种高性能通道隔离硬件，主要用于支持其干涉测量系统（Interferometer Systems）。此类模块通常用于精密测量和运动控制应用中，提供信号隔离和数据稳定性，从而提高测量系统的可靠性和精确度。

产品特点：

1. 高性能信号隔离：

   • 提供通道间的电气隔离，防止噪声和干扰影响干涉测量信号的稳定性。
   • 减少测量信号中因电气干扰引起的误差。

2. 兼容性强：

   • 专为 Zygo 的 ZMI 系列激光干涉仪（如 ZMI-501 系统）设计，确保与系统的无缝集成。

3. 可靠性高：

   • 工业级设计，可在复杂环境下稳定工作。
   • 提供电流过载和短路保护，延长模块寿命。

4. 模块化设计：

   • 易于安装、更换和维护，减少系统停机时间。

技术参数：

• 型号：8010-0105-02
• 系列：ZMI-501
• 功能：通道信号隔离，用于数据完整性和干扰抑制。
• 兼容设备：Zygo ZMI 系列干涉仪和相关运动控制系统。
• 输入/输出通道：支持多通道输入和输出。
• 电气隔离等级：高隔离电平，确保测量信号的独立性和精确性。
• 工作环境：
  • 温度范围：通常在工业标准范围内（建议查阅具体手册）。
  • 抗震能力：适用于高精度测量的实验室或工业场景。

英文资料：

Zygo 8010-0105-02 ZMI-501 channel isolation board is a high-performance channel isolation hardware provided by Zygo, mainly used to support its interferometer systems. This type of module is commonly used in precision measurement and motion control applications, providing signal isolation and data stability to improve the reliability and accuracy of measurement systems.

Product features:

High performance signal isolation:

Provide electrical isolation between channels to prevent noise and interference from affecting the stability of interferometric measurement signals.

Reduce errors caused by electrical interference in measurement signals.

Strong compatibility:

Specially designed for Zygo's ZMI series laser interferometers (such as the ZMI-501 system) to ensure seamless integration with the system.

High reliability:

Industrial grade design, capable of stable operation in complex environments.

Provide current overload and short circuit protection to extend module lifespan.

Modular design:

Easy to install, ｒｅｐｌａｃｅ, and maintain, reducing system downtime.

Technical parameters:

Model: 8010-0105-02

Series: ZMI-501

Function: Channel signal isolation, used for data integrity and interference suppression.

Compatible devices: Zygo ZMI series interferometers and related motion control systems.

Input/Output Channels: Supports multi-channel input and output.

Electrical isolation level: high isolation level, ensuring the independence and accuracy of measurement signals.

Work environment:

Temperature range: usually within the industrial standard range (recommended to refer to specific manuals).

Seismic resistance: suitable for laboratory or industrial scenarios with high-precision measurement.

2.产      品      展      示
