DANAHER ZMP-SYNQNET-PCI 运动控制模块

DANAHER ZMP-SYNQNET-PCI 运动控制模块

1.产 品 资 料 介 绍：

中文资料：

DANAHER ZMP-SYNQNET-PCI 是一款 高性能 PCI 运动控制模块，用于 多轴运动控制系统，主要应用于 精密自动化、机器人、数控机床、半导体制造、电子装配等领域。它采用 SynqNet 作为通信协议，提供高速、实时的分布式运动控制，适用于高精度同步控制和复杂运动轨迹的应用。

1. 产品概述

• 制造商：DANAHER Motion
• 产品型号：ZMP-SYNQNET-PCI
• 产品类型：PCI 运动控制模块
• 总线接口：PCI（标准 32-bit 插槽）
• 通信协议：SynqNet（高带宽实时运动控制网络）
• 典型应用：
  • 多轴运动控制（CNC 机床、机器人）
  • 电子制造、半导体设备
  • 3D 打印、激光切割、光学检测
  • 自动化流水线
  • 高精度定位系统

2. 主要技术参数

3. 主要特点

✅ 支持 SynqNet 通信协议：SynqNet 是一种专为运动控制优化的 实时以太网协议，支持分布式 I/O 和多个运动轴的同步控制。
✅ 高轴数支持：可以扩展 多达 32 轴 的运动控制，适用于大规模自动化生产设备。
✅ 高速数据传输：支持 100Mbps 通信速率，保证精确的运动控制。
✅ 精准同步控制：纳秒级同步能力，确保多轴协同运动，适用于激光加工、3D 打印等高精度应用。
✅ PCI 即插即用：采用标准 PCI 插槽，兼容 工业 PC、CNC 控制器 等设备，便于集成。
✅ 强大的软件支持：提供 SDK 开发工具包，支持 C/C++、LabVIEW、Matlab 等开发环境，可自定义控制算法。
✅ 兼容各种反馈设备：支持 增量编码器、绝对值编码器、模拟/数字信号反馈，适应不同传感器。

英文资料：

DANAHER ZMP-SYNQNET-PCI is a high-performance PCI motion control module used in multi axis motion control systems, mainly applied in precision automation, robotics, CNC machine tools, semiconductor manufacturing, electronic assembly and other fields. It adopts SynqNet as the communication protocol, providing high-speed and real-time distributed motion control, suitable for high-precision synchronous control and applications with complex motion trajectories.

1. Product Overview

manufacturer: DANAHER Motion

Product model: ZMP-SYNQNET-PCI

Product type: PCI motion control module

Bus interface: PCI (standard 32-bit slot)

Communication Protocol: SynqNet (High bandwidth Real time Motion Control Network)

Typical applications:

Multi axis motion control (CNC machine tools, robots)

Electronic manufacturing, semiconductor equipment

3D printing, laser cutting, optical inspection

Automated assembly line

High precision positioning system

2. Main technical parameters

Parameter specifications

Communication interface PCI bus

Control Network SynqNet

Supports 4-32 axes (depending on configuration)

Data transmission rate up to 100Mbps

Synchronization accuracy nanosecond level (suitable for high-precision synchronization control)

I/O expansion compatible with external I/O modules

Feedback support supports multiple encoder feedbacks (incremental/absolute encoder)

Operating system compatibility with Windows/Linux (based on dedicated SDK)

Real time hardware level real-time performance, supporting motion trajectory planning

Typical control methods include position control, speed control, and torque control

3. Main features

✅  Support SynqNet communication protocol: SynqNet is a real-time Ethernet protocol optimized for motion control, supporting distributed I/O and synchronous control of multiple motion axes.

✅  High axis support: can expand motion control up to 32 axes, suitable for large-scale automated production equipment.

✅  High speed data transmission: Supports 100Mbps communication rate to ensure precise motion control.

✅  Precise synchronization control: nanosecond level synchronization capability ensures multi axis coordinated motion, suitable for high-precision applications such as laser processing and 3D printing.

✅  PCI Plug and Play: Using standard PCI slots, compatible with industrial PCs, CNC controllers, and other devices for easy integration.

✅  Powerful software support: provides SDK development toolkit, supports C/C++, LabVIEW, Matlab and other development environments, and can customize control algorithms.

✅  Compatible with various feedback devices: support incremental encoder, absolute encoder, analog/digital signal feedback, and adapt to different sensors.
