Siemens 6SN1123-1AA00-0DA1 电源模块
1.产 品 资 料 介 绍：
中文资料：
Siemens 6SN1123-1AA00-0DA1 是 SIMODRIVE 611 系列中的 电源模块（Power Module），用于工业自动化系统中的驱动供电。该模块可为 数控机床（CNC）、伺服驱动系统、机器人 和其他工业应用提供稳定的电源。
主要技术参数
- 系列：SIMODRIVE 611
- 额定输入电压：三相 380-480V AC
- 输出电压：直流 600V DC（母线电压）
- 额定电流：适用于 中等功率范围的驱动系统
- 功率范围：根据负载情况，适用于 伺服驱动、主轴驱动 等
- 冷却方式：风冷，确保长时间运行的稳定性
- 保护功能：过压、过流、短路保护，提高系统可靠性
- 通讯接口：支持 PROFIBUS / SERCOS（需匹配控制单元）
产品特点
- 高效能量管理：提供 直流母线 供电，可回馈能量，提升整体能效
- 模块化设计：可与 SIMODRIVE 611 驱动系统 兼容，支持扩展
- 动态响应快：适用于高精度伺服控制
- 适应恶劣环境：具备良好的耐温、抗震和抗电磁干扰能力
- 易于维护：支持 热插拔、更换简便
应用领域
Siemens 6SN1123-1AA00-0DA1 广泛应用于 高性能自动化控制系统，主要涉及：
数控机床（CNC）
- 车床、铣床、加工中心的伺服驱动
- 主轴电机供电
机器人与自动化设备
- 机器人驱动系统
- 生产线自动化
材料加工
- 轧钢机、印刷机、造纸机械等高负载设备
物流与搬运
- 自动化仓储系统（AGV 机器人）
- 输送带、堆垛机驱动控制
能源回馈与测试设备
- 机电测试平台
- 工业电机试验台
英文资料：
Siemens 6SN1123-1AA00-0DA1 is a power module in the SIMODRIVE 611 series, used for driving power supply in industrial automation systems. This module can provide stable power supply for CNC machines, servo drive systems, robots, and other industrial applications.
Main technical parameters
Series: SIMODRIVE 611
Rated input voltage: three-phase 380-480V AC
Output voltage: DC 600V DC (bus voltage)
Rated current: suitable for drive systems in the medium power range
Power range: Suitable for servo drive, spindle drive, etc. according to load conditions
Cooling method: air-cooled to ensure stability during long-term operation
Protection function: overvoltage, overcurrent, short circuit protection to improve system reliability
Communication interface: Supports PROFIBUS/SERCOS (requires matching control unit)
Product Features
Efficient energy management: providing DC bus power supply, feedback energy, and improving overall energy efficiency
Modular design: compatible with SIMODRIVE 611 driver system and supports expansion
Fast dynamic response: suitable for high-precision servo control
Adapting to harsh environments: possessing excellent temperature resistance, earthquake resistance, and electromagnetic interference resistance capabilities
Easy to maintain: supports hot plugging and easy replacement
application area
Siemens 6SN1123-1AA00-0DA1 is widely used in high-performance automation control systems, mainly involving:
Numerical Control Machine Tool (CNC)
Servo drive for lathes, milling machines, and machining centers
Main spindle motor power supply
Robots and Automation Equipment
Robot Drive System
Production line automation
material processing
High load equipment such as rolling mills, printing machines, and paper making machinery
Logistics and Handling
Automated Warehouse System (AGV Robot)
Drive control of conveyor belt and stacker crane
Energy feedback and testing equipment
Mechanical and Electrical Testing Platform
Industrial motor test bench
2.产 品 展 示
