INDRAMAT TVM2.4-050-220/300-W1 电源模块

INDRAMAT TVM2.4-050-220/300-W1 电源模块

1.产 品 资 料 介 绍：

中文资料：

INDRAMAT TVM2.4-050-220/300-W1 电源模块主要用于为 INDRAMAT 伺服驱动系统 提供稳定的直流电源，广泛应用于工业自动化设备。以下是其详细技术参数和应用领域：

技术规格

1. 型号：TVM2.4-050-220/300-W1
2. 额定直流输出电流：50 A
3. 输入电压：三相 AC 220V / 50-60 Hz
4. 直流母线电压：DC 300V
5. 控制电源输入：单相 AC 115V 或 220V / 50-60 Hz
6. 冷却方式：内置风扇冷却
7. 兼容性：适用于 INDRAMAT 的多种伺服驱动器和控制系统

产品特点

1. 高可靠性：适用于高负载、高精度工业自动化设备。
2. 模块化设计：易于集成至现有 INDRAMAT 伺服系统。
3. 稳定的直流电源输出：确保伺服驱动系统的高精度运行。
4. 过载保护：内置保护机制，防止电流过载损坏设备。
5. 风扇冷却系统：高效散热，确保长时间稳定运行。
6. 维护简便：模块化结构便于更换和维护。

应用领域

1. 数控机床：为 CNC 机床中的伺服驱动器提供稳定的电源。
2. 工业自动化：应用于机器人、自动化装配线等设备。
3. 包装机械：用于高精度包装设备中的驱动控制系统。
4. 印刷行业：为高速印刷设备提供可靠的电源。
5. 纺织机械：支持高精度纺织设备的稳定运行。
6. 物流搬运：如自动化仓储系统的伺服控制。
7. 木工机械：确保木工加工设备的精确操作。

英文资料：

The INDRAMAT TVM2.4-050-220/300-W1 power module is mainly used to provide stable DC power for the INDRAMAT servo drive system and is widely used in industrial automation equipment. Here are its detailed technical parameters and application areas:

technical specifications

model: TVM2.4-050-220/300-W1

Rated DC output current: 50 A

Input voltage: three-phase AC 220V/50-60 Hz

DC bus voltage: DC 300V

Control power input: single-phase AC 115V or 220V/50-60 Hz

Cooling method: Built in fan cooling

Compatibility: Suitable for various servo drives and control systems of INDRAMAT

Product Features

High reliability: suitable for high load, high-precision industrial automation equipment.

Modular design: easy to integrate into existing INDRAMAT servo systems.

Stable DC power output: ensures high-precision operation of the servo drive system.

Overload protection: Built in protection mechanism to prevent damage to equipment caused by current overload.

Fan cooling system: efficient heat dissipation, ensuring long-term stable operation.

Easy to maintain: The modular structure is easy to ｒｅｐｌａｃｅ and maintain.

application area

Numerical Control Machine Tool: Provides stable power supply for servo drives in CNC machine tools.

Industrial automation: applied to equipment such as robots and automated assembly lines.

Packaging Machinery: Used as a drive control system in high-precision packaging equipment.

Printing industry: providing reliable power supply for high-speed printing equipment.

Textile Machinery: Supports stable operation of high-precision textile equipment.

Logistics handling: such as servo control of automated warehousing systems.

Woodworking machinery: Ensure precise operation of woodworking processing equipment.

2.产      品      展      示
