CONVERTEAM MVRL2100/4601液体冷却器模块

CONVERTEAM  MVRL2100/4601液体冷却器模块

1.产 品 资 料 介 绍：

中文资料：

MVRL2100-4601 是由 Converteam（现为 GE Energy）生产的 液体冷却整流模块，主要用于 MV3000 DELTA 驱动系统。该模块的主要功能是将交流电源转换为未经平滑处理的直流电源，为中压驱动系统提供可靠的直流电源支持。

主要特点：

• 双六脉冲整流器设计：每个模块包含两个三相六脉冲整流器，可独立连接交流输入，提供灵活的配置选项。

• 支持12脉冲网络桥接：通过外部供电变压器实现30°相移，并使用桥间变压器连接两个直流正输出，可配置为12脉冲整流，降低谐波失真。

• 预充电电路：内置预充电电路，可通过限流电阻为晶体管模块的直流链电容充电，确保系统安全启动。

• 液体冷却设计：采用液体冷却方式，提高散热效率，适用于高功率密度的应用场景。

• 温度监测：配备热敏电阻和温控器，实时监测模块温度，提供过温保护，确保系统稳定运行。

应用领域：

• 中压驱动系统：广泛应用于工业自动化领域，为中压电机和驱动设备提供稳定的直流电源。

• 电力传输与分配：在电力系统中，用于将交流电转换为直流电，满足特定设备的供电需求。

• 可再生能源：在风力和水力发电系统中，用于整流和电能转换，提高能源利用效率。

技术规格：

• 最大直流输出电压：1250 VDC

• 冷却方式：液体冷却

• 安装方式：兼容标准 DELTA 安装框架

英文资料：

MVRL2100-4601 is a liquid cooled rectifier module produced by Converteam (now GE Energy), mainly used for the MV3000 DELTA drive system. The main function of this module is to convert AC power into unsmoothed DC power, providing reliable DC power support for medium voltage drive systems.

Main features:

Double six pulse rectifier design: Each module contains two three-phase six pulse rectifiers that can be independently connected to AC inputs, providing flexible configuration options.

Support 12 pulse network bridging: achieve a 30 ° phase shift through an external power transformer, and connect two DC positive outputs using an inter bridge transformer. It can be configured as a 12 pulse rectifier to reduce harmonic distortion.

Pre charging circuit: Built in pre charging circuit, which can charge the DC link capacitor of the transistor module through a current limiting resistor to ensure safe system startup.

Liquid cooling design: Adopting liquid cooling method to improve heat dissipation efficiency, suitable for high power density application scenarios.

Temperature monitoring: equipped with thermistor and temperature controller, real-time monitoring of module temperature, providing over temperature protection to ensure stable system operation.

Application areas:

Medium voltage drive system: widely used in the field of industrial automation, providing stable DC power supply for medium voltage motors and drive equipment.

Power transmission and distribution: In the power system, it is used to convert alternating current into direct current to meet the power supply needs of specific equipment.

Renewable energy: used in wind and hydroelectric power systems for rectification and energy conversion to improve energy utilization efficiency.

Technical specifications:

Maximum DC output voltage: 1250 VDC

Cooling method: liquid cooling

Installation method: Compatible with standard DELTA installation framework
