HORNER ELECTRIC HE693RTD600M输入模块

HORNER ELECTRIC HE693RTD600M输入模块

1.产 品 资 料 介 绍：

中文资料：

HORNER ELECTRIC HE693RTD600M 是一款 RTD（电阻温度检测）输入模块，用于 GE Fanuc 90-30 PLC 系列，实现温度信号的采集和处理。它支持多种类型的 RTD 传感器，广泛应用于温度监测、过程控制和工业自动化等领域。

主要特点：

1. 兼容性

   • 专为 GE Fanuc 90-30 PLC 设计，易于集成到现有自动化控制系统中。

   • 兼容 Horner Electric 自动化设备，适用于工业环境中的温度监测。

2. 输入通道

   • 提供 6 个 RTD 输入通道，支持多个 RTD 传感器同时连接。

3. 支持的 RTD 类型

   • 支持多种常见的 RTD 传感器类型，包括：

     • Pt100（100Ω 铂 RTD）

     • Pt1000（1000Ω 铂 RTD）

     • Ni120（120Ω 镍 RTD）

     • Cu10（10Ω 铜 RTD）

4. 温度测量范围

   • Pt100: -200°C 至 +850°C

   • Pt1000: -200°C 至 +850°C

   • Ni120: -80°C 至 +260°C

   • Cu10: -100°C 至 +260°C

5. 精度与分辨率

   • 分辨率：0.1°C

   • 精度：±0.1%（根据传感器类型和测量范围而变化）

6. 冷端补偿

   • 采用 自动冷端补偿 技术，以提高测量准确性，减少外部温度变化对测量的影响。

7. 通信与数据传输

   • 提供 数字化输出，可通过 PLC 程序 访问采集的温度数据，并进行实时监控与控制。

8. LED 状态指示

   • 模块上配有 LED 指示灯，用于显示输入状态、故障警告和运行状况，便于操作和维护。

英文资料：

HORNER ELECTRIC HE693RTD600M is an RTD (Resistance Temperature Detection) input module used in the GE Fanuc 90-30 PLC series to collect and process temperature signals. It supports multiple types of RTD sensors and is widely used in fields such as temperature monitoring, process control, and industrial automation.

Main features:

compatibility

Specially designed for GE Fanuc 90-30 PLC, easy to integrate into existing automation control systems.

Compatible with Horner Electric automation equipment, suitable for temperature monitoring in industrial environments.

Channel

Provide 6 RTD input channels and support simultaneous connection of multiple RTD sensors.

Supported RTD types

Supports multiple common types of RTD sensors, including:

Pt100 (100 Ω platinum RTD)

Pt1000 (1000 Ω platinum RTD)

Ni120 (120 Ω nickel RTD)

Cu10 (10 Ω copper RTD)

Temperature measurement range

Pt100: -200 ° C to+850 ° C

Pt1000: -200 ° C to+850 ° C

Ni120: -80 ° C to+260 ° C

Cu10: -100 ° C to+260 ° C

Accuracy and Resolution

Resolution: 0.1 ° C

Accuracy: ± 0.1% (varies depending on sensor type and measurement range)

Cold Junction Compensation

Adopting automatic cold end compensation technology to improve measurement accuracy and reduce the impact of external temperature changes on measurement.

Communication and Data Transmission

Provide digital output, which can access the collected temperature data through PLC program and perform real-time monitoring and control.

LED status indication

The module is equipped with LED indicator lights to display input status, fault warnings, and operating conditions for easy operation and maintenance.

2.产      品      展      示
