HORNER ELECTRIC HE693THM889C模拟热电偶输入模块

HORNER ELECTRIC HE693THM889C模拟热电偶输入模块

1.产 品 资 料 介 绍：

中文资料：

HORNER ELECTRIC HE693THM889C 是一款 模拟热电偶输入模块，专为 GE Fanuc 90-30 PLC 系列设计，能够接收来自热电偶的模拟信号并转换为数字信号。它被广泛应用于工业自动化控制系统中，尤其是在需要高精度温度监控和控制的应用场合。

主要特点：

1. 兼容性与集成

   • 专为 GE Fanuc 90-30 PLC 系列设计，适用于 Horner Electric 系列自动化控制系统。

   • 可通过 Proficy Machine Edition 或 Logicmaster 90 软件进行配置与编程。

   • 完美兼容其他 Horner Electric 产品，易于与现有系统集成。

2. 输入通道

   • 提供 8 个独立的模拟热电偶输入通道，每个通道均可接收来自热电偶传感器的信号。

   • 模块支持多种类型的热电偶，包括 K型、J型、T型、E型、R型、S型、B型、N型 等。

3. 热电偶类型支持

   • 支持常见的 K型、J型、T型、E型、R型、S型、B型、N型 等热电偶。

   • 该模块根据不同热电偶类型提供温度测量，并能够根据不同的工作环境和要求选择适当的热电偶类型。

4. 精度与分辨率

   • 提供高精度的温度数据采集功能，精度可达到 ±0.25% 或更高，确保精确测量和可靠数据输出。

   • 分辨率可达到 0.1°C，使得温度变化能够被及时且精确地捕捉。

5. 自动冷端补偿功能

   • 该模块具有 自动冷端补偿功能，能够补偿热电偶冷端的温度变化，确保温度数据的准确性。

   • 即使冷端温度发生变化，也能准确反映热电偶端的温度，提升数据的可靠性。

6. 模拟信号转换

   • 该模块支持 模拟信号输入，并将其转换为 数字信号，用于后续的处理和控制。

   • 输出的数字信号可以通过 PLC 程序进一步处理，用于温度控制或报警系统。

7. 状态指示与报警功能

   • 配备 LED 指示灯，显示模块的运行状态，包括信号输入状态、正常运行以及故障警告。

   • 提供 报警输出，当温度超出设定范围或模块发生故障时，及时发出警告。

8. 多通道设计

   • 支持多达 8 个独立通道，允许用户同时连接多个热电偶传感器，进行多点温度监测。

   • 每个通道具有独立的输入和输出设置，适用于复杂的工业控制系统。

英文资料：

HORNER ELECTRIC HE693THM889C is an analog thermocouple input module designed specifically for the GE Fanuc 90-30 PLC series, capable of receiving analog signals from thermocouples and converting them into digital signals. It is widely used in industrial automation control systems, especially in applications that require high-precision temperature monitoring and control.

Main features:

Compatibility and Integration

Specially designed for GE Fanuc 90-30 PLC series, suitable for Horner Electric series automation control systems.

Configuration and programming can be done through Proficy Machine Edition or Logicmaster 90 software.

Perfectly compatible with other Horner Electric products and easy to integrate with existing systems.

Channel

Provide 8 independent analog thermocouple input channels, each of which can receive signals from thermocouple sensors.

The module supports multiple types of thermocouples, including K-type, J-type, T-type, E-type, R-type, S-type, B-type, N-type, etc.

Thermocouple type support

Supports common types of thermocouples such as K, J, T, E, R, S, B, N, etc.

This module provides temperature measurement based on different thermocouple types and can ｓｅｌｅｃｔ the appropriate thermocouple type according to different working environments and requirements.

Accuracy and Resolution

Provide high-precision temperature data acquisition function, with an accuracy of ± 0.25% or higher, ensuring accurate measurement and reliable data output.

The resolution can reach 0.1 ° C, allowing temperature changes to be captured in a timely and accurate manner.

Automatic cold end compensation function

This module has an automatic cold end compensation function, which can compensate for temperature changes in the cold end of thermocouples and ensure the accuracy of temperature data.

Even if the temperature at the cold end changes, it can accurately reflect the temperature at the thermocouple end, improving the reliability of the data.

Analog signal conversion

This module supports analog signal input and converts it into digital signals for subsequent processing and control.

The output digital signals can be further processed through PLC programs for temperature control or alarm systems.

Status indication and alarm function

Equipped with LED indicator lights to display the operating status of the module, including signal input status, normal operation, and fault warnings.

Provide alarm output to promptly issue a warning when the temperature exceeds the set range or the module malfunctions.

Multi-channel Design

Supports up to 8 independent channels, allowing users to connect multiple thermocouple sensors simultaneously for multi-point temperature monitoring.

Each channel has independent input and output settings, suitable for complex industrial control systems.
