HORNER ELECTRIC HE693ADC816D分析输入模块

HORNER ELECTRIC  HE693ADC816D分析输入模块

1.产 品 资 料 介 绍：

中文资料：

HORNER ELECTRIC HE693ADC816D 是一款高性能的 模拟输入模块，专为 GE Fanuc 90-30 PLC 系列设计。该模块支持多通道的模拟信号输入，并能够执行精确的信号采集与分析，广泛应用于需要高精度数据采集的工业自动化系统中。

主要特点：

1. 兼容性与集成

   • 专为 GE Fanuc 90-30 PLC 系列设计，并可与 Horner Electric 的其他控制产品兼容。

   • 可通过 Proficy Machine Edition 或 Logicmaster 90 软件进行配置和编程，确保与现有自动化系统的无缝集成。

2. 输入通道

   • 提供 16 个独立的模拟输入通道，每个通道支持 差分输入 或 单端输入，适用于各种模拟信号采集场景。

   • 每个输入通道都能够处理多种类型的模拟信号，如电压、毫伏、毫安等。

3. 高精度与高分辨率

   • 分辨率：16 位分辨率，能够精确地捕获细微的模拟信号变化。

   • 精度：±0.1% 或更高，确保采集到的数据非常精确，适用于要求高精度的控制系统。

4. 输入信号类型

   • 支持 电压输入（0-10V、±10V等）和 电流输入（4-20mA等），使得该模块能够满足不同类型信号的输入需求。

   • 支持 差分输入模式，能够有效抑制电气噪声，提供更加稳定的信号采集。

5. 采样与更新速率

   • 支持 高采样率，能够快速采集数据并实时传输至 PLC 系统。

   • 可根据需求配置不同的更新频率，确保实时数据的获取与处理。

6. 输入通道配置与灵活性

   • 每个通道支持独立配置，用户可选择差分或单端模式，并根据需要配置不同的输入范围。

   • 支持自定义输入标定，能够满足特定设备或传感器的要求。

7. 状态指示与报警功能

   • 配备 LED 指示灯，显示模块状态，包括输入信号的状态、模块工作情况以及故障警告。

   • 提供 报警功能，当输入信号超出设定的阈值时，会发出警告，便于及时采取措施。

8. 扩展性与兼容性

   • 可通过 Horner Electric 系列的 I/O 扩展模块，进一步扩展输入通道数，满足大规模自动化系统的需求。

   • 与其他 Horner Electric 自动化控制设备兼容，可以形成高效、灵活的自动化控制系统。

英文资料：

HORNER ELECTRIC HE693ADC816D is a high-performance analog input module designed specifically for the GE Fanuc 90-30 PLC series. This module supports multi-channel analog signal input and can perform precise signal acquisition and analysis, widely used in industrial automation systems that require high-precision data acquisition.

Main features:

Compatibility and Integration

Specially designed for the GE Fanuc 90-30 PLC series and compatible with other control products from Horner Electric.

It can be configured and programmed through Proficy Machine Edition or Logicmaster 90 software to ensure seamless integration with existing automation systems.

Channel

Provide 16 independent analog input channels, each supporting differential input or single ended input, suitable for various analog signal acquisition scenarios.

Each input channel can handle multiple types of analog signals, such as voltage, millivolts, milliamps, etc.

High precision and high resolution

Resolution: 16 bit resolution, capable of accurately capturing subtle analog signal changes.

Accuracy: ± 0.1% or higher, ensuring that the collected data is very accurate, suitable for control systems that require high precision.

Input Signal Type

Supports voltage input (0-10V, ± 10V, etc.) and current input (4-20mA, etc.), enabling the module to meet the input requirements of different types of signals.

Supporting differential input mode, it can effectively suppress electrical noise and provide more stable signal acquisition.

Sampling and ｕｐｄａｔｅ rate

Support high sampling rate, able to quickly collect data and transmit it in real-time to the PLC system.

Different ｕｐｄａｔｅ frequencies can be configured according to requirements to ensure real-time data acquisition and processing.

Input channel configuration and flexibility

Each channel supports independent configuration, and users can choose differential or single ended mode, and configure different input ranges as needed.

Support custom input calibration to meet the requirements of specific devices or sensors.

Status indication and alarm function

Equipped with LED indicator lights to display module status, including input signal status, module operation status, and fault warnings.

Provide alarm function, which will issue a warning when the input signal exceeds the set threshold, facilitating timely action.

Scalability and compatibility

The Horner Electric series of I/O expansion modules can further expand the number of input channels to meet the needs of large-scale automation systems.

Compatible with other Horner Electric automation control equipment, it can form an efficient and flexible automation control system.

2.产      品      展      示
