Alcatel-Lucent 3CM03285MK通信模块

 ALCATEL LUCENT 3CM03285MK通信模块

1.产 品 资 料 介 绍：

中文资料：

产品型号：3CM03285MK
制造商：Alcatel-Lucent（现为诺基亚 Nokia）
产品类别：通信模块 / 接口处理模块
用途：用于通信系统中数据交互、接口扩展、协议处理等任务

功能概述：

1. 提供设备间或系统间的通信接口，具备高速数据传输能力

2. 支持主控与子模块、模块与网络之间的协议解析与信息交换

3. 可用于通信系统中控制链路或数据链路的建立和维护

4. 模块具备一定的协议栈处理能力，支持SNMP、以太网、串口等接口协议（依据配置）

技术特性（典型配置）：

• 接口类型：可能包含高速以太网或串口接口

• 工作电压：由机框或主板统一供电

• 安装方式：插槽式热插拔设计

• 工作温度范围：-5℃ 至 +55℃，适应通信机房环境

• 管理支持：可通过主设备监控软件或命令行接口进行管理和配置

适用设备：
适用于Alcatel-Lucent的多种核心网或接入网平台，包括但不限于：

• 宽带接入平台（如ISAM系列）

• 传输系统设备

• 无线通信控制器等

使用注意事项：

• 安装前应确认模块插槽及电源匹配

• 替换需断电或确保支持热插拔

• 系统检测到模块后，应进行版本与配置匹配校验

英文资料：

Product model: 3CM03285MK

Manufacturer: Alcatel Lucent (now Nokia)

Product category: Communication module/Interface processing module

Purpose: Used for tasks such as data exchange, interface expansion, protocol processing, etc. in communication systems

Function Overview:

Provide communication interfaces between devices or systems, with high-speed data transmission capabilities

Support protocol parsing and information exchange between the main control and sub modules, modules and networks

Can be used for establishing and maintaining control or data links in communication systems

The module has certain protocol stack processing capabilities and supports interface protocols such as SNMP, Ethernet, serial port, etc. (depending on configuration)

Technical characteristics (typical configuration):

Interface type: may include high-speed Ethernet or serial port interface

Working voltage: uniformly powered by the chassis or motherboard

Installation method: Slot style hot swappable design

Working temperature range: -5 ℃ to+55 ℃, suitable for communication room environment

Management support: can be managed and configured through the main device monitoring software or command-line interface

Applicable equipment:

Suitable for various core or access network platforms of Alcatel Lucent, including but not limited to:

Broadband access platform (such as ISAM series)

Transmission system equipment

Wireless communication controller, etc

Precautions for use:

Before installation, it is necessary to confirm that the module slot and power supply match

Replacement requires power outage or ensuring support for hot swapping

After the system detects the module, it should perform version and configuration matching verification

2.产      品      展      示
