ALCATEL-LUCENT 3DH03164AAAA发射器模块

 ALCATEL LUCENT 3DH03164AAAA发射器模块

1.产 品 资 料 介 绍：

中文资料：

ALCATEL-LUCENT 3DH03164AAAA 发射器模块技术解析

1. 产品定位

该模块属于光通信发射单元，用于将电信号转换为光信号（E/O转换），主要部署在阿尔卡特朗讯光传输和宽带接入设备中，支持高速数据的光纤传输。

2. 核心功能特性

3. 典型应用场景

(1) 光传输网络（OTN/DWDM）

• 在1830 PSS平台中作为客户侧光接口，实现业务信号的光电转换和波长复用。

• 支持100G/200G相干传输系统的子模块（如用于CFP2光模块内部）。

(2) 宽带接入（PON/FTTx）

• 作为GPON OLT的上行光发射模块，连接城域核心网。

• 在企业专线中提供10G LAN-PHY或WAN-PHY接口。

(3) 数据中心互联（DCI）

• 用于数据中心交换机（如7750 SR）的短距/长距光互联，支持SR/LR/ER等标准。

英文资料：

Technical Analysis of ALCATEL-LUCENT 3DH03164AAAA Transmitter Module

1. Product positioning

This module belongs to the optical communication transmission unit, which is used to convert electrical signals into optical signals (E/O conversion). It is mainly deployed in Alcatel Lucent optical transmission and broadband access equipment, supporting high-speed data fiber transmission.

2. Core functional features

Parameter Technical Specifications (Typical Values) Description

Single mode fiber (SMF) suitable for wavelengths of 1310nm/1550nm

Transmission rates of 1G/10G/25G support SDH, Ethernet, and OTN protocols

Transmitting power -3dBm~+5dBm meets Class 1 laser safety standards

Transmission distance of 10km/40km/80km, available in different power versions

Design of interface type SFP+/XFP pluggable optical module

Operating temperature -5 ° C~+70 ° C Industrial grade temperature adaptability

3. Typical application scenarios

(1) Optical Transmission Network (OTN/DWDM)

As a customer side optical interface in the 1830 PSS platform, it achieves optoelectronic conversion and wavelength multiplexing of business signals.

Support submodules for 100G/200G coherent transmission systems (such as those used inside CFP2 optical modules).

(2) Broadband access (PON/FTTx)

As the upstream optical transmission module of GPON OLT, it connects to the metropolitan core network.

Provide 10G LAN-PHY or WAN-PHY interfaces in enterprise dedicated lines.

(3) Data Center Interconnection (DCI)

Used for short/long distance optical interconnection of data center switches (such as 7750 SR), supporting standards such as SR/LR/ER.
