ALCATEL-LUCENT 3CM03285MP交换板

 ALCATEL LUCENT  3CM03285MP交换板

1.产 品 资 料 介 绍：

中文资料：

ALCATEL-LUCENT 3CM03285MP 交换板技术规格

1. 产品概述

• 型号：3CM03285MP

• 类型：高性能交换矩阵板

• 定位：用于阿尔卡特朗讯（诺基亚）核心交换设备，提供高容量数据交换能力

2. 核心功能特性

3. 技术参数

4. 典型应用场景

1. 核心路由器交换矩阵

   • 用于7950 XRS核心路由器

   • 支持400G线卡互联

2. 数据中心骨干交换

   • 构建CLOS架构叶脊网络

   • 支持ECMP多路径负载均衡

3. 5G核心网承载

   • 处理UPF用户面高速交换

   • 支持网络切片隔离

英文资料：

ALCATEL-LUCENT 3CM03285MP Switch Board Technical Specifications

1. Product Overview

Model: 3CM03285MP

Type: High performance switching matrix board

Positioning: Used for Alcatel Lucent (Nokia) core switching equipment, providing high-capacity data exchange capabilities

2. Core functional features

Characteristic Technical Description

Switching capacity 3.2Tbps full duplex

Forwarding mode based on cell based switching architecture

Delay performance<2 μ s (64 byte message)

Redundant design N+1 load sharing architecture

Expansion capability supports online capacity upgrade

3. Technical parameters

Parameter specifications

Backplane interface 16x200G QSFP-DD

Heat dissipation method: liquid cooling+air cooling mixed heat dissipation

Power consumption 450W (full load)

Working temperature 5 ° C~40 ° C

MTBF >200, 000 hours

4. Typical application scenarios

Core router switching matrix

Used for 7950 XRS core router

Support 400G line card interconnection

Backbone Exchange in Data Centers

Building a CLOS architecture leaf spine network

Support ECMP multi-path load balancing

5G core network carrier

Handling high-speed exchange of UPF user interface

Support network slicing isolation

2.产      品      展      示
