ALCATEL LUCENT 3AL86708ACAC控制器模块

ALCATEL LUCENT  3AL86708ACAC控制器模块

1.产 品 资 料 介 绍：

中文资料：

ALCATEL-LUCENT 3AL86708ACAC 控制器模块 是一款专用于阿尔卡特朗讯（Alcatel-Lucent）电信系统设备中的高性能控制类板卡，广泛应用于核心网络、光纤传输、DSL接入平台等通信架构中，承担系统控制、信令管理、协议调度与运行状态监控等核心任务。

一、基本信息概览

二、核心功能

1. 系统控制与调度管理

   • 作为整机主控模块，统筹协调所有业务板卡的运行状态、资源分配与任务调度。

   • 执行启动初始化、配置加载、运行控制等任务。

2. 信令与协议处理

   • 支持多种电信协议（如 IP/MPLS、SDH、ATM、以太网等）的控制平面处理。

   • 管理链路状态、路由策略、信号同步等网络控制逻辑。

3. 状态监控与告警输出

   • 实时监测整机运行参数（电压、电流、温度等），异常自动告警。

   • 板卡本身具备 LED 指示灯，显示运行状态、故障状态。

4. 远程管理与维护接口

   • 提供用于设备管理的串口、以太网管理口等，支持 Telnet、SNMP、Web GUI 等维护协议。

   • 支持远程升级、参数配置、日志下载。

5. 与其他模块互联通信

   • 通过高速背板总线与业务模块、接口模块等进行高速数据/信令交换。

英文资料：

The ALCATEL-LUCENT 3AL86708ACAC controller module is a high-performance control board specifically designed for Alcatel Lucent telecommunications system equipment. It is widely used in communication architectures such as core networks, fiber optic transmission, and DSL access platforms, undertaking core tasks such as system control, signal management, protocol scheduling, and operational status monitoring.

1、 Overview of Basic Information

Project Content

Product model 3AL86708ACAC

Product Name Controller Module

Manufacturer Alcatel Lucent (now part of Nokia Communications Group)

Applicable platforms may be used for Alcatel Lucent's ISAM, 1850TSS, S12, or transmission devices

2、 Core functions

System Control and Scheduling Management

As the main control module of the whole machine, it coordinates the operation status, resource allocation, and task scheduling of all business cards.

Perform tasks such as startup initialization, configuration loading, and run control.

Signaling and Protocol Processing

Support control plane processing for multiple telecommunications protocols such as IP/MPLS, SDH, ATM, Ethernet, etc.

Manage network control logic such as link status, routing strategy, and signal synchronization.

Status monitoring and alarm output

Real time monitoring of the operating parameters of the entire machine (voltage, current, temperature, etc.), automatic alarm for abnormalities.

The board itself has LED indicator lights that display the operating status and fault status.

Remote management and maintenance interface

Provide serial ports, Ethernet management ports, etc. for device management, supporting maintenance protocols such as Telnet, SNMP, Web GUI, etc.

Support remote upgrade, parameter configuration, and log download.

Interconnect and communicate with other modules

Perform high-speed data/signaling exchange with business modules, interface modules, etc. through a high-speed backplane bus.

2.产      品      展      示
