ALCATEL LUCENT 3AL36010AAAB
继电器功能模块（Relay Board）

产品概述：

3AL36010AAAB 在特定 Alcatel-Lucent 系统中也可能集成有 继电器控制功能，通常用于电信设备中的控制电路，用以实现信号切换、设备状态响应、线路保护等功能。

此类模块具备多组可控继电器输出，可被控制系统通过程控指令远程控制，从而影响电源、通信线路或其他设备状态，广泛用于运营商机房、基站和接入节点设备。

核心功能特点：

• 多通道继电器输出：支持多路继电器通道，可单独控制开关状态。

• 远程控制与响应机制：继电器动作可由主控板发出命令远程触发，具备自动故障响应能力。

• 过流保护设计：内部具备对继电器触点的电流过载保护功能，防止电路损坏。

• 状态指示功能：继电器状态可实时反馈至系统监控软件，用于诊断和维护。

• 高电气隔离性：具备良好的光电隔离/磁隔离能力，适合信号与强电分离的工业环境。

典型应用领域：

1. 通信设备电源切换控制

   • 在阿尔卡特朗讯通信机架中控制整流器、UPS 电源或负载侧通断。

2. 远程重启与故障转移

   • 实现对远端通信单元的断电重启，或在故障情况下切换至备用电路。

3. 设备告警与状态控制

   • 与系统告警模块联动，在通信异常时触发继电器动作，点亮信号灯或报警蜂鸣器。

4. 工业自动化信号控制

   • 应用于 Alcatel Lucent 控制系统接入工业现场设备，实现继电器级联动作。

5. 安全联锁系统

   • 用于通信系统中实现硬件联锁，避免误操作或非法接入。

英文资料：

ALCATEL LUCENT 3AL36010AAAB

Relay Board Function Module

Product Overview:

3AL36010AAB may also be integrated with relay control functions in specific Alcatel Lucent systems, typically used in control circuits in telecommunications equipment to achieve signal switching, device status response, line protection, and other functions.

This type of module has multiple sets of controllable relay outputs, which can be remotely controlled by the control system through programmable instructions, thereby affecting the status of power supply, communication lines or other equipment. It is widely used in operator rooms, base stations and access node equipment.

Core functional features:

Multi channel relay output: Supports multiple relay channels and can independently control switch status.

Remote control and response mechanism: Relay action can be remotely triggered by commands issued by the main control board, with automatic fault response capability.

Overcurrent protection design: It has an internal current overload protection function for relay contacts to prevent circuit damage.

Status indication function: The relay status can be fed back in real-time to the system monitoring software for diagnosis and maintenance.

High electrical isolation: It has good photoelectric/magnetic isolation capabilities and is suitable for industrial environments where signals and strong electricity are separated.

Typical application areas:

Communication equipment power switching control

Control the on/off of rectifiers, UPS power supplies, or load side in Alcatel Lucent communication racks.

Remote restart and failover

Implement power-off and restart of remote communication units, or switch to backup circuits in case of faults.

Equipment alarm and status control

Linked with the system alarm module, it triggers relay action and lights up the signal light or alarm buzzer in case of communication abnormalities.

Industrial automation signal control

Applied to Alcatel Lucent control system connected to industrial field equipment to achieve relay cascade action.

Safety Interlock System

Used to implement hardware interlocking in communication systems to avoid misoperation or illegal access.

2.产      品      展      示
