ALCATEL LUCENT 3AL92113AA04电源模块

ALCATEL LUCENT  3AL92113AA04电源模块

1.产 品 资 料 介 绍：

中文资料：

✅ 产品名称：

ALCATEL LUCENT 3AL92113AA04
电源模块 / Power Supply Module

✅ 产品概述：

3AL92113AA04 电源模块 是 Alcatel-Lucent 通信设备系统中的关键供电组件，设计用于为通信系统中的主控单元、接口模块、传输设备等提供稳定、连续的直流电源。该模块通常具备高稳定性、高效率和热插拔特性，以满足运营商级系统对电力供应的高可靠性要求。

✅ 核心功能特点：

• 稳压输出：可将输入的交流或直流电源稳定转换为系统所需的特定电压值（如 -48V、+12V、+5V 等）。

• 过载保护：内建过压、过流、短路保护机制，防止系统受损。

• 高可靠性：满足电信级设备对长时间连续运行的电源需求。

• 热插拔支持：允许在设备运行中更换电源模块，无需关闭整机。

• 冗余设计：支持与其他电源模块并联运行，提供冗余备份，提高系统容错率。

✅ 产品技术规格（典型参数，具体以设备型号为准）：

• 输入电压范围：AC 100–240V 或 DC -48V（根据配置）

• 输出电压：通常为 DC +12V / +5V / -48V

• 最大输出功率：数百瓦到上千瓦不等

• 接口类型：背板插槽接口，带通信反馈引脚

• 工作温度范围：-5°C 至 +55°C

• 冷却方式：风冷或强制通风散热

英文资料：

✅  Product Name:

ALCATEL LUCENT 3AL92113AA04

Power Supply Module

✅  Product Overview:

The 3AL92113AA04 power module is a key power supply component in Alcatel Lucent communication equipment systems, designed to provide stable and continuous DC power to the main control unit, interface module, transmission equipment, etc. in the communication system. This module typically has high stability, high efficiency, and hot swappable characteristics to meet the high reliability requirements of operator level systems for power supply.

✅  Core functional features:

Stabilized output: It can stably convert the input AC or DC power supply into specific voltage values required by the system (such as -48V,+12V,+5V, etc.).

Overload protection: Built in overvoltage, overcurrent, and short-circuit protection mechanisms to prevent system damage.

High reliability: meets the power requirements of telecom grade equipment for long-term continuous operation.

Hot swappable support: allows for the replacement of power modules during device operation without the need to shut down the entire machine.

Redundant design: supports parallel operation with other power modules, provides redundant backup, and improves system fault tolerance.

✅  Product technical specifications (typical parameters, specific to equipment model):

Input voltage range: AC 100-240V or DC -48V (depending on configuration)

Output voltage: usually DC+12V/+5V/-48V

Maximum output power: ranging from several hundred watts to several kilowatts

Interface type: Backplane slot interface with communication feedback pin

Working temperature range:- 5 ° C to+55 ° C

Cooling method: Air cooling or forced ventilation for heat dissipation

2.产      品      展      示
